Yokogawa UR1BG3-008N-020102-LZ-N/CN Rotary Displacement Flowmeter

  • roduct Introduction: It is a positive displacement flowmeter based on the rotary displacement principle, designed for accurate measurement of low - to - medium viscosity liquids. It has high measurement accuracy and good repeatability, and is suitable for flow measurement of lubricating oil, fuel oil, chemical solvents and other media in industrial processes.
  • Technical Specifications:
    • Pipe Size: DN20 (3/4 inch), 8mm nominal diameter.
    • Flow Range: 0.05-2m³/h (liquid dependent).
    • Accuracy: ±0.15% of reading.
    • Repeatability: ±0.05% of reading.
    • Working Temperature: -20~80°C.

Yokogawa DM1100A00-1 Digital Multimeter Module

  • Product Introduction: It is a high - precision digital multimeter module designed for Yokogawa's industrial measurement and control systems. It provides accurate measurement of AC/DC voltage, current, resistance, capacitance and other electrical parameters, and integrates seamlessly with the system to meet the electrical parameter monitoring needs in industrial automation and power monitoring scenarios.
  • Technical Specifications:
    • Measurement Functions: AC/DC voltage, AC/DC current, resistance, capacitance, frequency, diode test, continuity test.
    • DC Voltage Range: 0-1000V, accuracy ±0.02% of reading.
    • AC Voltage Range: 0-750V (50/60Hz), accuracy ±0.05% of reading.
    • DC Current Range: 0-10A, accuracy ±0.03% of reading.

Yokogawa AQ7275 Optical Time Domain Reflectometer

Technical Specifications:

  • Wavelength: 850/1300nm (multimode fiber), 1310/1550/1650nm (single - mode fiber).
  • Dynamic Range: Up to 45dB (1650nm, high - range model), 40dB (1310/1550nm typical)cdn.tmi.yokogawa.com.
  • Event Dead Zone: 0.8m (typical), enabling detection of closely spaced eventscdn.tmi.yokogawa.com.
  • Sampling Resolution: 5cm - 32m adjustable; readout resolution 1cm (minimum).
  • Data Storage: Internal memory stores up to 128,000 data points; supports USB storage expansion.
  • Power Supply: Rechargeable lithium - ion battery, 10 - second startup; AC adapter (100-240V AC)cdn.tmi.yokogawa.com.
  • Weight: Approximately 9kg, portable for field use.

Yokogawa HR2400 Hybrid Strip Chart Recorder

Technical Specifications:

  • Number of Channels: Up to 30 universal analog input channels, 3 - channel dot matrix recording.
  • Input Signal: DCV, mV, thermocouple (K, J, T, E, R, S, B, etc.), RTD (Pt100, JPt100), 4-20mA DC; pressure measurement with external transducer.
  • Accuracy: ±0.1% of full scale for standard input signals.
  • Recording Speed: 1-999mm/h adjustable.
  • Display: Digital LED display for real - time data reading.
  • Power Supply: 100-240V AC, 50/60Hz, power consumption ≤ 50VA.
  • Communication Interface: RS - 232, RS - 422/485 (Modbus RTU), optional GPIB interface.

Yokogawa 253710-D/M3/C7 Terminal Block

Technical Specifications:

  • Type: Spring - type terminal block, suitable for 1.5-2.5mm² cables.
  • Rated voltage: 600V AC.
  • Rated current: 20A.
  • Contact resistance: ≤1mΩ.
  • Insulation resistance: ≥100MΩ.
  • Working temperature: -40~85°C.
  • Material: High - temperature resistant engineering plastic (housing), copper alloy (contact).

Yokogawa AXF025C-NNAL1L-BA11-2NB

Technical Specifications:

  • Pipe diameter: DN25 (1 inch).
  • Measurement accuracy: ±0.35% of rate (0.2% of rate optional for high - precision type).
  • Flow range: 0.05-10m/s.
  • Fluid temperature: -40~160°C (general type), -10~160°C (sanitary type).
  • Fluid conductivity: ≥5μS/cm.
  • Output signal: 4-20mA DC, pulse output, HART communication.
  • Power supply: 100-240V AC or 24V DC.
  • Protection level: IP67 (sensor), IP65 (converter).

Yokogawa OR342-2 Digital Output Relay Module

Technical Specifications:

  • Number of channels: 8 independent relay output channels.
  • Output contact capacity: 250V AC, 5A per channel (resistive load).
  • Response time: ≤10ms.
  • Working voltage: 24V DC, current consumption ≤ 200mA.
  • Isolation: 2kV AC between output and system for 1 minute.
  • Working temperature: -20~70°C.
  • Connection method: Screw terminal, easy to wire and maintain.

Yokogawa CX2410-1-0-1 Data Acquisition Module

Technical Specifications:

  • Number of channels: 4 isolated analog input channels.
  • Input signal: 4-20mA DC, 1-5V DC, thermocouple (K, J, T, E, etc.), RTD (Pt100).
  • Measurement accuracy: ±0.05% of full scale.
  • Data update cycle: 10ms.
  • Isolation: 500V AC between channels, 1.5kV AC between input and system for 1 minute.
  • Working voltage: 24V DC, current consumption ≤ 100mA.
  • Working temperature: -20~70°C.

Yokogawa DY040-EBMAA1D/FF1/SCT

Technical Specifications:

  • Measured medium: Liquid, gas, steam (avoid multiphase flow and viscous fluid).
  • Measurement accuracy: ±0.75% of reading (liquid), ±1% of reading (gas, steam).
  • Repeatability: ±0.2% of reading.
  • Process temperature: -29~250°C (general type).
  • Process pressure: Up to 10MPa.
  • Output signal: 4-20mA DC current output, FOUNDATION Fieldbus (FF1) digital communication.
  • Power supply: 10.5-42V DC.
  • Connection method: Wafer or flange connection, stainless steel tag plate (SCT option)quote.us.yokogawa.com

Yokogawa AXFA14C-E1-21/CF1

Technical Specifications:

  • Communication protocol: FOUNDATION Fieldbus (FF1).
  • Input signal: The signal from the magnetic flowmeter sensor (the induced voltage generated by the fluid cutting magnetic field).
  • Output signal: 4-20mA DC current output, pulse output (up to 20000 PPS).
  • Power supply: 100-240V AC or 100-120V DC.
  • Working temperature: -40~60°C (explosion - proof type).
  • Explosion - proof certification: CSA certification (CF1 option).
  • Connection method: 1/2”NPT electrical connection.

Yokogawa FX106-4-2 4-Channel Paperless Videographic Recorder

Technical Specifications:

  • Number of input channels: 4 isolated analog input channels.
  • Input signal: Support thermocouple (R, S, B, K, E, J, T, N, etc.), RTD (Pt100, JPt100), 4-20mA DC and 1-5V DC signals.
  • Measurement interval: 1s, 2s optional.
  • Storage capacity: Built - in 128MB flash memory, supporting external CF card expansion (up to 2GB).
  • Display: 5.5 - inch TFT color LCD, multiple display modes (trend graph, digital value, bar graph, etc.).
  • Power supply: 100-240V AC, 50/60Hz, power consumption ≤ 35VA.
  • Protection level: IP65 (front panel).

Yokogawa UT450-00 Digital Indicating Controller

Technical Specifications:

  • Input type: Universal input, supporting thermocouple (R, S, B, K, E, J, T, N, etc.), RTD (Pt100, JPt100), 4-20mA DC and 1-5V DC signals.
  • Measurement accuracy: ±0.1% of full scale.
  • Input sampling period: 200ms.
  • Control output: Relay contact output (250V AC, 5A), voltage pulse output (12V DC, 100mA), 4-20mA DC current output (optional).
  • Power supply: 100-240V AC, 50/60Hz, power consumption ≤ 10VA.
