Yokogawa TM13001045-2SN Temperature Transmitter Module

Technical Specifications:

  • Input: Thermocouple (K, J, T, E, R, S, B) or RTD (Pt100, JPt100).
  • Output: 4-20mA DC, 2 - wire loop - powered.
  • Accuracy: ±0.1% of full scale (thermocouple); ±0.05% of full scale (RTD).
  • Cold Junction Compensation: Built - in, accuracy ±0.2°C.
  • Operating Temperature: -40~85°C.
  • Power Supply: 10.5-42V DC.
  • Isolation: 500V AC between input and output.
  • Enclosure: Aluminum, IP65 protection.

Yokogawa YF108-AAUE4D-S3S3 DigitalYEWFLO Vortex Flowmeter

Technical Specifications:

  • Measured Media: Liquid, gas, steam (no multiphase flow or viscous fluids).
  • Accuracy: ±0.75% of reading (liquid); ±1% of reading (gas, steam).
  • Repeatability: ±0.2% of reading.
  • Process Temperature: -29~250°C (standard).
  • Process Pressure: Up to 10MPa.
  • Output: 4-20mA DC, pulse, HART 7.0 (AAUE4D option).
  • Power Supply: 10.5-42V DC.
  • Connection: Wafer (S3S3 option), stainless steel tag plate.

Yokogawa F3RP42-5P

Technical Specifications:

  • Channel Count: 5 isolated pulse input channels.
  • Input Type: Dry contact, NPN/PNP open collector, 5-24V DC.
  • Pulse Frequency: Up to 100kHz per channel.
  • Count Range: 32 - bit unsigned (0-4,294,967,295).
  • Isolation: 500V AC between channels and system.
  • Power Supply: 24V DC, current consumption ≤ 150mA.
  • Operating Temperature: -20~70°C.
  • Output: Digital count values via FA - M3 backplane bus.

Yokogawa UR5HG3-010N-1AB-2TA-N/CN

Technical Specifications:

  • Pipe Size: DN10 (3/8 inch), 10mm nominal diameter.
  • Flow Range: 0.1-10m³/h (liquid dependent).
  • Accuracy: ±0.15% of reading.
  • Repeatability: ±0.05% of reading.
  • Working Pressure: Up to 2.5MPa.
  • Working Temperature: -10~80°C.
  • Output Signal: Pulse output (up to 1000Hz), 4-20mA DC (optional, 2TA option).
  • Material: Cast iron housing, stainless steel piston and rotor.
  • Connection: Flange (1AB option), NPT thread (N/CN option).

Yokogawa JEFMC-B011-06F Fieldbus Power Conditioner

Technical Specifications:

  • Bus Type: FOUNDATION Fieldbus H1 (1.25Mbps).
  • Output Voltage: 12-32V DC, compliant with FF H1 specifications.
  • Output Current: 600mA per segment, supports up to 16 field devices per segment.
  • Isolation: 500V AC between power input and fieldbus segments; 250V AC between segments.
  • Protection: Overvoltage, overcurrent, reverse polarity, and surge protection (6kV transient).
  • Power Input: 24V DC redundant input.
  • Operating Temperature: -40~70°C.
  • Physical: DIN - rail mountable, aluminum alloy housing for durability.

Yokogawa UP550-00 1/4 DIN Program Controller

  • Product Introduction: It is a 1/4 DIN-sized program controller belonging to Yokogawa's Green Series, designed for precise program control of industrial process parameters like temperature, pressure, and flow. It integrates program pattern storage, multi-mode control, and real-time display, and has been discontinued with replacement model UP55A-000-11-00. It offers reliable control for heat treatment, chemical synthesis, and other batch processes requiring step - wise parameter changes.
  • Technical Specifications:
    • Input Type: Universal input, supporting thermocouple (K, J, T, E, R, S, B, etc.), RTD (Pt100, JPt100), 4-20mA DC, 1-5V DC, and mV signals.
    • Measurement Accuracy: ±0.1% of full scale.
    • Sampling Period: 100ms, 200ms, 500ms selectable.
    • Program Capacity: 30 program patterns, 300 segments, 400 events, 8 PV events, 16 time events.
    • Control Modes: Single - loop, cascade, loop with PV auto - selector, position proportional, heating/cooling control.

Yokogawa UR1BG3-008N-020102-LZ-N/CN Oval Gear Flowmeter

echnical Specifications:

  • Nominal Diameter: DN8 (0.3 inch).
  • Flow Range: 0.01-0.2m³/h (liquid dependent).
  • Accuracy: ±0.2% of reading.
  • Repeatability: ±0.05% of reading.
  • Working Pressure: Up to 2.5MPa.
  • Working Temperature: -10~80°C.
  • Output Signal: Pulse output (up to 1000Hz), optional 4-20mA DC.
  • Material: Cast iron (housing), stainless steel (gears).

Yokogawa AAT141-S00 Analog Temperature Input Module

  • Product Introduction: It is a 16 - channel analog temperature input module designed for Yokogawa's CENTUM VP distributed control system. It directly accepts signals from thermocouples and RTDs, converts them into digital signals for the DCS controller, and is suitable for temperature measurement in industrial processes.
  • Technical Specifications:
    • Number of Channels: 16 isolated channels.
    • Input Signal: Thermocouple (K, J, T, E, R, S, B, etc.), RTD (Pt100, JPt100).
    • Accuracy: ±0.1% of full scale for thermocouple; ±0.05% of full scale for RTD.
    • Cold Junction Compensation: Built - in, accuracy ±0.2°C.
    • Working Voltage: 24V DC, power consumption ≤ 350mA.

Yokogawa SDV531-S63/PRP Safety Digital Valve Positioner

  • Product Introduction: It is a safety - related digital valve positioner designed for control valves in industrial processes. It is used to accurately control the valve opening according to the control signal from the safety instrumented system (SIS), ensuring the safe operation of the valve in emergency situations, and is compatible with FOUNDATION Fieldbus communication.
  • Technical Specifications:
    • Safety Integrity Level: SIL 3, compliant with IEC 61508 and IEC 61511.
    • Input Signal: 4-20mA DC, FOUNDATION Fieldbus (PRP option).
    • Output Signal: Pneumatic signal (0.02-0.1MPa).
    • Valve Positioning Accuracy: ±0.5% of full stroke.

Yokogawa F3SP71-4S Safety Relay Module

  • Product Introduction: It is a safety relay module belonging to Yokogawa's ProSafe - RS safety instrumented system, designed based on IEC 61508 standard, with SIL 3 safety integrity level. It is used to implement safety interlock logic and emergency shutdown functions in industrial processes to ensure the safety of personnel and equipment.
  • Technical Specifications:
    • Safety Integrity Level: SIL 3, compliant with IEC 61508 and IEC 61511.
    • Number of Channels: 4 safety - related relay output channels.
    • Output Contact Capacity: 250V AC, 5A per channel (resistive load).
    • Response Time: ≤ 10ms.
    • Working Voltage: 24V DC, power consumption ≤ 250mA.

Yokogawa AAI143-S00 Analog Input Module

  • Product Introduction: It is a 16 - channel analog input module designed for Yokogawa's CENTUM VP distributed control system. It is used to collect 4-20mA DC analog signals from field instruments, convert them into digital signals for processing by the DCS controller, and is suitable for large - scale data acquisition in industrial processes.
  • Technical Specifications:
    • Number of Channels: 16 isolated channels.
    • Input Signal: 4-20mA DC.
    • Accuracy: ±0.05% of full scale.
    • Sampling Rate: 10 samples per second per channel.
    • Working Voltage: 24V DC, power consumption ≤ 300mA.

Yokogawa ADV159-P00 Differential Pressure Transmitter

  • Product Introduction: It is a high - performance differential pressure transmitter belonging to Yokogawa's SMARTDAC+ data acquisition system. It is used to measure the differential pressure of gases, liquids and vapors, and convert it into a standard electrical signal for transmission, which is suitable for flow, liquid level and pressure measurement in industrial processes.
  • Technical Specifications:
    • Measurement Range: 0-1kPa to 0-10MPa differential pressure.
    • Accuracy: ±0.075% of full scale.
    • Output Signal: 4-20mA DC with HART 7.0 protocol.
    • Power Supply: 24V DC (2 - wire system), current consumption ≤ 4mA.
    • Working Temperature: -40~85°C.
