ABB PNI800 Plant Network Interface Module

1. Technical Specifications • Dimensions: 243.84 mm depth × 73.66 mm height × 170.18 mm width • Weight: 0.5 kg net • Power Supply: 24 V DC (18–36 V) • Operating Temperature: −25 °C to +70 °C • Environmental: RoHS compliant, G3 corrosive-gas rated • Communication Ports: Two independent Ethernet 10/100 Mbit RJ-45 ports plus two isolated RS-232/RS-485 serial ports • Protocols: Modbus RTU/TCP, Ethernet/IP, PROFINET, PN800/TriStation, IEC 61850 GOOSE, UDP, TCP/IP • Redundancy: Dual-attached node for PRP (IEC 62439) redundant LANs (PN800A & PN800B) • LED Indicators: Link, activity, fault per port

FOXBORO FCP280 Field Control Processor

1. Technical Specifications • Processor: ARM-based control processor with 128 MB SDRAM and 128 MB flash memory • I/O Capacity: Up to 128 Fieldbus Modules (FBMs) per controller – 200-series FBM: 32 per HDLC fieldbus link, 4 links total → 128 max – 100-series FBM: 64 per link or mixed configurations up to 128 total • Communication: – Fieldbus: 2 Mbps HDLC (200-series) or 268 kbps HDLC (100-series) – Control network: 100 Mbps copper or fiber Ethernet with dual-redundant adapters • Control Blocks: 8 000 configurable blocks, 16 000 blocks per second throughput • Scan Period: 50 ms minimum block processing cycle • Power: 24 VDC ±20 %, < 15 W typical • Environmental: −40 °C to +70 °C, G3 corrosive-gas rated, CE-marked for field mounting • Housing: Rugged die-cast aluminum enclosure, IP20 front, IP50 rear with cover

ABB UNS0867 HIEE405246R0002 Excitation & I/O Extension Card

UNS0867 HIEE405246R0002 is marketed as both a high-performance excitation control board (UNS 0867A-P, V2) and a plug-in I/O extension card for ABB Advant OCS and AC 800M systems. All variants share the same physical board and are factory-flashed for the target application.

ABB PM511V16 Processor Module

1. Technical Specifications • Processor: Motorola MC68040 running at 25 MHz • Memory: – Version PM511V08: 8 MB dynamic RAM with ECC – Version PM511V16: 16 MB dynamic RAM with ECC (upgrade kit available) • Storage: system program held on PCMCIA flash card (program card) • Power supply: 24 VDC ±20 %, consumed via backplane • Mechanical: single-slot 6U VME board, 160 mm × 160 mm × 120 mm, 0.8 kg • Operating temperature: 0 °C to +70 °C • Indicators: front-panel LEDs and four-position rotary switch for start / mode selection plus restart push-button

GE 369-HI-R-M-0-0-0-E Motor Management Relay

echnical Specifications • Control power: HI range 50–300 VDC or 60–265 VAC 50/60 Hz, 20 VA nominal • Motor protection functions: overload, short-circuit, locked-rotor, phase-loss, phase-reversal, ground-fault, under- and over-voltage, under- and over-frequency, power factor, thermal modeling • Current inputs: 1 A or 5 A secondary, true RMS 1.04 ms/sample, burden < 0.5 VA • RTD inputs: 12 channels, isolated 36 Vpk, supports 100 Ω Pt, Ni, Cu elements • Metering package: real-time current, voltage, power, energy, frequency, power factor accuracy ±0.5 % • Digital inputs: 6 opto-isolated, 24–250 VDC/AC • Output contacts: 4 Form-C relay outputs, 8 A make, 5 A carry • Analog outputs: 4 optional 0–1 mA / 0–20 mA / 4–20 mA, 0.5 % accuracy • Communication: front RS-232, rear RS-485 (3 ports), Modbus RTU; optional Modbus TCP/IP, Profibus-DP/DPV1, DeviceNet

ABB DSDP170 57160001-ADF High-Performance Pulse Counting & Positioning Module

1. Technical Specifications • Product type: high-speed pulse counting board for the ABB S100 I/O system • Max. pulse frequency: 2.5 MHz • Positioning accuracy: ±0.05 % of measured value • Speed measuring range: 0 – 5 000 RPM • Counting resolution: software-selectable 1×, 2×, 4×, 8× • Input voltage range: 5 – 24 VDC, universal for most encoders and sensors • Output frequency: 30 kHz • Dimensions: 328.5 mm × 18 mm × 238.5 mm • Weight: 0.38 kg • Protection: IP20 module housing, designed for 19-inch rack / DIN-rail sub-rack mounting • Environmental rating: −20 °C to +60 °C operating, 95 % RH non-condensing • Certifications: CE, UL, RoHS compliant

ABB LM80.A — Laser Level Transmitter

he LM80.A is a non-contact, time-of-flight laser level transmitter engineered for continuous level, distance or positioning measurement of solids, opaque liquids and slurries. The instrument emits a narrow-beam laser pulse, measures the reflection time and calculates the exact distance to the material surface without physical contact .

ABB PPC907BE101 3BHE024577R0101 High-Performance Industrial Control Module

PPC907BE101 3BHE024577R0101 is a core control board within ABB’s AMC34 series, engineered for demanding medium- and high-voltage drive applications. It is factory-installed in ACS2000, ACS5000 and ACS6000 drive families and serves as the central application and motor-control computer for these systems.
Technical Specifications • Processor: dual-core ARM Cortex-A9, 800 MHz or dual-core 1.2 GHz (depending on revision) • Memory: 256 MB DDR3 RAM, 512 MB Flash (minimum); 2 GB DDR3 + 8 GB Flash variants exist • I/O handling: > 5 000 transactions per second, 8 analog inputs, 8 analog outputs, 32 digital I/O

ABB KSD211B 3BHE022455R1101 — High-Integrity Servo Drive Module

1. Technical Specifications • Supply voltage: three-phase 380–480 V AC ±10 % • Continuous output current: 16 A • Peak current (3 s): 48 A • Control method: field-oriented vector control (FOC) with auto-tuning PID • Positioning accuracy: ±0.02 mm (with 17-bit absolute encoder) • Loop update rate: 1 kHz (current), 4 kHz (speed), 1 kHz (position) • Feedback: absolute encoder, resolver, or incremental encoder • Communication: CANopen, RS-485, ABB Robot Network, EtherNet/IP via expansion • Safety: STO (Safe Torque Off) and SS1 (Safe Stop 1) certified to SIL 2 / ISO 13849-1 Cat. 3 • Response time to safety command: ≤ 50 ms • Regenerative braking: built-in, returns up to 25 % of braking energy to DC bus • Operating temperature: 5 °C to 45 °C (derating above 40 °C) • Protection class: IP20 (cabinet-mounted) with conformal coating • Dimensions: 200 mm W × 300 mm H × 150 mm D • Weight: 2.8 kg

ABB AO2000 LS25 Laser Gas Analyzer – Comprehensive Technical Profile

1. Core Technology & Performance • Measurement principle: Tunable Diode Laser Absorption Spectroscopy (TDLAS) • Target gases: O₂, CO, CO₂, NOₓ, NH₃, HCl and other IR-active species—range selectable by configuration • Accuracy: ±2 ppm or ±2 % of reading, whichever is greater • Response time (T₉₀): ≤1 second • Sensitivity: sub-ppm level dependent on gas and path length • Drift: < 1 % per month with automatic baseline correction

ABB CI867K01 Communication Interface

Technical Specifications

  1. Electrical & Physical Parameters:
    • Power Supply: 24 V DC ±20%.
    • Power Consumption: ≤4.5 W.
    • Operating Temperature: 0°C to +55°C (storage: -40°C to +85°C).
    • Dimensions: 127.5 mm (H) × 59 mm (W) × 185 mm (D).
    • Weight: 0.7 kg (standard configuration).
    • Protection Rating: IP20 (EN60529/IEC 529 compliant).

ABB PPC907BE 3BHE024577R0101 – Complete Technical Profile

Technical Specifications

  1. Processor & Performance:
    • CPU: PowerPC 604e processor @ 400 MHz .
    • Memory: 256 MB SDRAM + 512 MB Flash storage .
    • I/O Capacity:
      • Digital I/O: Configurable up to 256 points (expandable via modules) .
      • Analog I/O: Supports multiple channels .
    • Execution Speed: Optimized for sub-millisecond scan times .
