Rated Voltage: 240 V AC (Single-Phase or Three-Phase)

Rated Power: 2.6 kW (2600 W)

Rated Torque: 8.3 Nm (Continuous)

Peak Torque: 24.9 Nm (3× Rated, 3 Seconds)

Rated Speed: 3000 RPM

Max Speed: 4500 RPM

Configuration Code: CE — Specific Winding/Feedback Variant

Shaft Type: P — With Keyway

Brake: B — Electromagnetic Holding Brake (24 V DC, 8.3 Nm)

Feedback: Incremental Encoder (Typically 2500 PPR, A/B/Z, Line Driver)

Insulation Class: Class F (155°C)

Protection Rating: IP65 (with Connector Cap)

Housing Material: Aluminum Alloy (Die-Cast)

Weight (Approx.): 8.5 kg

Cooling Method: Forced Air (Internal Fan + External Blower Optional)

Key Features:

• High Power Density AC Servo Motor
• Integrated Holding Brake for Vertical Axis Applications
• Keyed Shaft for Positive Torque Transmission
• Wide Speed Range with Constant Torque
• IP65 Rated for Harsh Environments

Applicable Industries: CNC Spindles, Vertical Axis Robots, Conveyor Drives, Packaging Machines, Textile Equipment

Installation Requirements: Mount with Flange Bolts (M6), Ensure Fan Airflow Is Unobstructed, Connect Brake Wire Separately, Use 24 V DC Supply for Brake Coil
