B&R 0GH-IF260

Model Series: X20 System (IF = Input Field)

Product Overview:
The 0GH-IF260 is a 16-channel digital input module from B&R’s X20 I/O system. It is designed for acquiring binary (ON/OFF) signals from sensors, switches, and other field devices in industrial automation applications. The module connects to the X20 bus (Ethernet-based) and provides galvanically isolated input channels.

WhatApp
WeChat

Detailed content

Technical Specifications:

  • Module Type: Digital Input (DI)
  • Number of Channels: 16 channels
  • Input Voltage (Logic 1): 15 V DC to 30 V DC (24 V DC nominal)
  • Input Voltage (Logic 0): 0 V DC to 5 V DC
  • Input Type: PNP (sourcing) or NPN (sinking) — configurable per group
  • Input Current (Logic 1): Typically 5 mA per channel
  • Isolation Voltage: 500 V DC (channel-to-channel, channel-to-bus)
  • Input Filter: Adjustable debounce time (0.1 ms to 25.6 ms)
  • Communication Interface: X20 Link (100 Mbps Ethernet)
  • Bus Connection: RJ45 connector (X20 bus daisy-chain)
  • Power Supply: 24 V DC via X20 bus (no separate power supply required)
  • Power Consumption: Approximately 2.5 W (typical)
  • Protection Rating: IP20
  • Operating Temperature: 0 °C to +55 °C
  • Storage Temperature: -25 °C to +70 °C
  • Relative Humidity: 5% to 95% (non-condensing)
  • Dimensions (W × H × D): Approximately 45 mm × 90 mm × 75 mm
  • Weight: Approximately 0.12 kg
  • Mounting: DIN rail TS 35, 7.5 mm width per module

Functional Features:

  • 16 independent digital input channels
  • Configurable as PNP or NPN per 8-channel group
  • Adjustable hardware input filter to eliminate contact bounce
  • LED status indicators per channel (green = ON, off = OFF)
  • Galvanic isolation between all channels and bus
  • Hot-swap capable on X20 bus
  • Status diagnostics available via Automation Studio

Applicable Industries:
General industrial automation, assembly lines, conveyor systems, packaging machines, material handling, process control.

Installation Requirements:

  • Mount on standard DIN rail TS 35 (7.5 mm module width)
  • Connect to X20 bus via RJ45 daisy-chain topology
  • 24 V DC power is supplied through the X20 bus — no external power needed
  • Shielded cables recommended for long field wiring runs
  • Max bus length: 100 m (with repeater: up to 500 m)

Usage Notes:

  • Do not exceed 30 V DC on any input channel
  • Match input type (PNP/NPN) to field device wiring
  • Use shielded cable and ground shield at controller end only
  • Verify input filter setting matches mechanical switch debounce requirements
