Technical Specifications:

• Total Net Capacity: 265 L (Fridge: 185 L / Freezer: 80 L)
• Energy Efficiency Class: A++ (EU Energy Label 2021)
• Annual Energy Consumption: 152 kWh/year
• Noise Level: 35 dB(A)
• Climate Class: SN-T (operates from 10°C to 43°C ambient)
• Cooling Technology: Total NoFrost + TwinTech
• Refrigerant: R600a (Isobutane, GWP 3)
• Voltage: 220–240V / 50Hz
• Dimensions (H x W x D): 1772 mm x 540 mm x 549 mm (built-in, excluding door)
• Door Hinge: Right-hand, reversible
• Door Panel Ready: Yes — accepts custom kitchen door panel (not included)
• Freezer Star Rating: 4-star (****)
• Freezing Capacity: 4 kg/24h
• Weight (Net): 62 kg

Functional Features:

• Total NoFrost: Multi-airflow system prevents frost buildup on all surfaces — no manual defrosting required.
• TwinTech Cooling: Separate fan-driven evaporators for fridge and freezer compartments maintain independent humidity levels.
• FreshZone Crisper: Adjustable humidity drawer (80–90% RH) for optimal fruit and vegetable preservation.
• TasteLock Seal: Airtight seal on crisper drawer locks in freshness up to 2x longer.
• AutoSense: Automatically adjusts cooling based on door-opening frequency and ambient temperature.
• FastFreeze Function: Rapid temperature drop to -24°C for quick freezing of fresh food.
• Door Alarm: Audible alert if door remains open for more than 60 seconds.
• LED Interior Lighting: Energy-efficient, long-life LED strips on all shelves.
• SpillSafe Glass Shelves: Tempered glass with raised edges to contain liquid spills.
• Adjustable Feet: 4 leveling feet for perfect built-in alignment.

Material Composition:

• Interior Liner: ABS plastic with antimicrobial additive
• Shelves: Tempered safety glass with stainless steel trim
• Crisper Drawer: Clear polycarbonate with stainless steel handle
• Door Gasket: Replaceable magnetic PVC gasket
• Evaporator Cover: Aluminum with roll-bond construction
• Exterior: White (door-panel-ready finish)

Structural Features:

• Installation Type: Fully built-in / integrated under counter
• Door Panel: Customizable — accepts kitchen cabinet door panel up to 25 mm thick
• Hinge Position: Right-hand, field-reversible to left
• Handle Type: Integrated recessed handle (for custom panel) or bar handle option
• Defrost Drain: Automatic evaporation — no drain required

Working Principle:
R600a refrigerant circulates through two independent evaporator circuits (TwinTech). One evaporator with a fan serves the refrigerator compartment; a second dedicated evaporator with a separate fan serves the freezer. Total NoFrost technology continuously circulates dry air across both evaporators, preventing moisture from depositing as frost. The AutoSense controller monitors door-open frequency and adjusts compressor duty cycle and fan speed accordingly. The FastFreeze function temporarily overrides the thermostat to drive the freezer evaporator to -24°C.

Advantages & Highlights:

• R600a Refrigerant: Natural refrigerant with GWP of only 3 — the most environmentally friendly option available.
• Total NoFrost: Zero manual defrosting ever required.
• Door-Panel Ready: Fully customizable to match any kitchen design.
• TwinTech: Independent climate zones prevent flavor transfer and optimize food preservation.
• A++ Efficiency: Low energy consumption for a 265 L built-in unit.

Applicable Industries / Use Cases:

• Residential kitchen integration
• Kitchen showrooms and model homes
• Small apartment kitchens
• Boutique hotel kitchenettes

Installation Requirements:

• Cabinet Cut-Out: H 1775 mm x W 560 mm x D 550 mm (minimum)
• Ventilation: Minimum 10 mm gap at top and sides for air circulation.
• Electrical: Dedicated 10A circuit with earth, 220–240V / 50Hz.
• Water Connection: Not required (automatic defrost evaporation).
• Door Panel: Must be attached by installer — use approved AEG door panel kit.

Usage Precautions:

• Allow 24 hours after installation before plugging in (compressor oil settling).
• Do not block the rear ventilation grille — minimum 50 mm clearance required.
• Clean interior with mild soap and water — do not use abrasive cleaners or solvents.
• Replace the door gasket if it loses suction (test with paper test).
• R600a is flammable (A3 classification) — ensure no ignition sources near leaked refrigerant.
