Channels Supported:16

Module Compatibility:Single & Dual Redundant

Signal Type:Analog

Connection Method:M4 Screw

Weight:1.5kg

Insulation Resistance:100 MΩ or greater @ 500V DC

Withstand Voltage:500V AC for 1 minute

    The Yokogawa AEA4D-00 Terminal Boards are engineered to provide unparalleled reliability and precision in industrial settings. These boards are specifically designed for applications requiring high redundancy and robust signal integrity.

    Featuring a modular design, these boards can be seamlessly integrated into both single and dual redundant systems, ensuring continuous operation even under unexpected failures. This makes them ideal for critical industrial processes where downtime can lead to significant operational disruptions.

    Each board offers 16 dedicated channels for analog signals, allowing for flexible and efficient data transmission without the need for complex wiring. The use of M4 screw connections ensures a secure and stable connection, enhancing overall system stability.

    The AEA4D-00 Terminal Boards are built with advanced insulation resistance and withstand voltage capabilities, providing protection against electrical disturbances. This feature is crucial in harsh industrial environments where electrical noise and fluctuations are common.

    Manufactured from high-quality materials, these terminal boards are designed to withstand rigorous conditions, guaranteeing longevity and reducing maintenance requirements. They are compatible with a variety of components, including Yokogawa’s AAI135, AAI835, AAP135, and KS1 series, ensuring seamless integration within existing control systems.
