Siemens SM322 Digital Output Module, 6ES7 322-1BH01-0AA0
The Siemens SM322 Digital Output Module, 6ES7 322-1BH01-0AA0, is a compact yet powerful interface solution designed for seamless integration into the SIMATIC S7-300 family of programmable logic controllers. Ideal for applications requiring precise digital control, this module ensures reliable operation in harsh industrial environments.
Detailed content
Type:Digital Output Module
Module Series:S7-300
Output Quantity:16
Power Supply Voltage:120/230V AC
Current Capacity:1A
Isolation Type:Optically Isolated
Pin Configuration:20-Pin
Operating Temperature Range:-25°C to +60°C
Storage Temperature Range:-40°C to +85°C
Dimensions (WxHxD):132mm x 150mm x 51mm
Weight:0.326kg
Connectivity:Standard I/O connector
The Siemens 6ES7 322-1BH01-0AA0 SM322 Digital Output Module is a critical component for advanced industrial automation setups, offering unparalleled reliability and performance. Its robust design ensures stable operation across a wide range of temperatures, making it suitable for both manufacturing plants and remote industrial sites.
Featuring optically isolated outputs, this module minimizes electrical interference, ensuring precise signal transmission even under harsh conditions. With its 16 digital outputs, it caters to complex control scenarios, allowing for flexible integration into various control systems.
The 20-pin configuration enables seamless connection to Siemens S7-300 controllers, facilitating easy setup and maintenance. The compact size and lightweight design make it an ideal choice for space-constrained environments without compromising on functionality.
Designed with user convenience in mind, the module supports standard I/O connectors, simplifying the installation process and reducing the need for custom wiring. Additionally, the inclusion of diagnostics tools ensures quick troubleshooting and maintenance, enhancing operational efficiency.
Backed by Siemens’ commitment to quality and innovation, the 6ES7 322-1BH01-0AA0 SM322 Digital Output Module is designed to withstand the rigors of industrial environments, offering long-term reliability and cost-effective operation for manufacturers seeking to optimize their automation processes.
