Technical Specifications​

AMD Geode LX800 processor at 500 MHz, 64 MB DRAM, 128 kB NVRAM, 128 MB CompactFlash mass memory, 24 V DC supply with 19.2 to 30 V DC range, 8 digital inputs and 8 digital outputs, Ethernet, PROFIBUS and SERCOS II options, IP20, dimensions 175.4 x 120 x 75.9 mm, weight approximately 1.004 kg, operating temperature 5 to 55°C, storage temperature -25 to 70°C.

Functional Features​

IEC 61131 programming, motion logic integration, diagnostics and status display, CompactFlash project storage, fieldbus communication, digital I/O processing, connection to IndraMotion drive systems.

Application Scenarios​

Packaging machines, special-purpose machine tools, handling systems, assembly stations, printing equipment and mid-size automation cells requiring PLC plus servo coordination.

Performance Parameters​

Real-time control cycle suitable for logic and axis supervision, deterministic I/O update over Ethernet/PROFIBUS/SERCOS, stable operation with Rexroth IndraDrive and IndraMotion components.

Material Composition​

Industrial metal/electronic enclosure, PCB with processor and memory devices, CompactFlash socket, D-sub and RJ45 connectors, DIN/panel mounting hardware.

Structural Features​

Inline controller housing, integrated I/O terminals, fieldbus ports, CF card slot, status LEDs, optional LCD/RS-232 depending on exact CML40.2 variant.

Working Principle​

The CPU executes the control program from CompactFlash or internal memory, scans digital I/O, exchanges data with HMI and drives over Ethernet/PROFIBUS/SERCOS, performs logic and motion supervision, and stores process data in DRAM/NVRAM.

Installation Requirements​

Install in a control cabinet with 24 V DC filtered supply, ground the enclosure and shield cables, provide backplane/DIN mounting according to the exact L40 variant, maintain clearance for ventilation, use approved Rexroth accessories only.
