Technical Specifications

• Form Factor:
  • Type: PXIe Controller Module
  • Slot Compatibility: Fits into PXIe chassis slots
• Processor:
  • CPU: Intel Core i7-4600U processor (or similar model)
  • Number of Cores: Dual-core or quad-core depending on specific configuration
• Memory:
  • RAM: 8 GB of DDR3L memory (expandable options may vary)
• Storage:
  • Hard Drive: Solid State Drive (SSD) with options like 128 GB or 256 GB
  • Additional Storage: Supports additional external storage solutions if needed
• Connectivity:
  • Ethernet: Dual Gigabit Ethernet ports for network connectivity
  • USB Ports: Multiple USB ports, including USB 2.0 and USB 3.0
  • Serial Ports: Includes RS-232 or RS-485 serial ports for legacy communication
  • PCIe: PXIe interface for integration with PXIe modules and systems
• Operating System:
  • OS Compatibility: Typically supports Windows operating systems such as Windows 10 or Windows 7
  • NI Software: Compatible with National Instruments software platforms like LabVIEW and NI Measurement & Automation Explorer (MAX)
• Power Requirements:
  • Power Supply: Powered through the PXIe chassis
• Cooling:
  • Cooling Mechanism: Internal cooling systems to manage heat dissipation

Functional Features

• Integrated Controller:
  • Function: Acts as the central processing unit for PXIe systems, overseeing data management, communication between modules, and overall system operation.
• High Performance:
  • Processor: Equipped with a powerful Intel Core i7 processor, providing robust performance for demanding applications.
• Flexible Connectivity:
  • Expansion: Includes a variety of connectivity options such as Ethernet, USB, and serial ports to interface with different peripherals and external devices.
• Software Support:
  • NI Integration: Seamlessly integrates with National Instruments software, including LabVIEW and NI MAX, allowing for comprehensive system configuration and control.
• Fast Storage:
  • SSD: Utilizes SSD storage for rapid data access and improved system performance, with options for expansion based on application needs.
• Memory and Expansion:
  • RAM: Sufficient memory to handle complex data processing tasks and multitasking, with potential for expansion.

Application Scenarios

• Test and Measurement Systems:
  • Usage: Serves as the central controller in PXIe-based test and measurement systems, managing data acquisition, processing, and system coordination.
• Data Acquisition:
  • Integration: Suitable for high-speed data acquisition applications where processing power and connectivity are critical.
• Automated Test Systems:
  • Functionality: Ideal for controlling automated test systems that require precise timing and synchronization with PXIe modules.
• Embedded Control:
  • Deployment: Can be used in embedded control systems where PXIe modules are employed for real-time control and monitoring.
• Research and Development:
  • Applications: Utilized in R&D environments for developing and managing complex test systems, data acquisition setups, and experimental controls.
