Technical Specifications

• FPGA Device:
  • FPGA Model: Xilinx Virtex-5 LX110T
  • FPGA Logic Cells: Approximately 110,000 logic cells
  • Memory: 4 MB of DDR2 SRAM
• I/O Connectivity:
  • I/O Ports: Up to 64 user-configurable I/O lines
  • Connectivity: Includes high-speed serial transceivers and general-purpose I/O
  • Connector Type: Various connectors for I/O expansion, including custom connectors for specific applications
• Timing and Synchronization:
  • Clock Sources: Onboard clock sources with support for external clock inputs
  • Synchronization: Advanced timing and synchronization capabilities, including external trigger inputs and outputs
• Bus Interface:
  • PXIe Interface: PXIe interface for seamless integration with other PXIe modules and systems
• Software Support:
  • Development Environment: NI LabVIEW FPGA Module, Xilinx ISE Design Suite
  • Programming Languages: LabVIEW FPGA, VHDL, Verilog
• Power Requirements:
  • Voltage: 3.3 V and 5 V provided through the PXIe backplane

Functional Features

• High-Performance FPGA:
  • Utilizes a Xilinx Virtex-5 LX110T FPGA, providing high logic cell count and memory for complex digital signal processing and custom logic applications.
• Flexible I/O Configuration:
  • Features up to 64 I/O lines that can be configured for various functions, allowing for flexible and adaptable solutions tailored to specific needs.
• High-Speed Serial Communication:
  • Equipped with high-speed serial transceivers to support fast data transfer and communication between modules.
• Advanced Timing and Synchronization:
  • Offers sophisticated timing and synchronization capabilities, including support for external clock inputs and precise synchronization of multiple channels.
• Customizable Logic:
  • Users can implement custom digital logic, algorithms, and signal processing tasks directly within the FPGA using NI LabVIEW FPGA or Xilinx design tools.
• Scalable and Modular:
  • Designed for integration into scalable PXIe systems, enabling expansion and customization based on application requirements.
• Software Integration:
  • Supported by NI LabVIEW FPGA Module and Xilinx ISE Design Suite, facilitating development and deployment of FPGA-based solutions.

Application Scenarios

• Custom Signal Processing:
  • Ideal for applications requiring custom signal processing, such as filtering, modulation, and data manipulation.
• High-Speed Data Acquisition:
  • Useful in real-time data acquisition systems where high-speed processing and low-latency response are essential.
• Communication Systems:
  • Employed in communication systems for custom protocol implementation, data modulation, and demodulation.
• Embedded Control Systems:
  • Suitable for embedded control applications where FPGA-based logic provides flexibility and high performance.
• Automated Test Systems:
  • Enhances automated testing by offering custom test logic, timing, and control functionalities.
• Research and Development:
  • Supports R&D projects that require rapid prototyping and implementation of custom digital algorithms and signal processing techniques.
