Technical Specifications:

• Chassis Type:
  • Form Factor: PXIe (PXI Express)
• Slots:
  • Number of Slots: 18
  • Slot Types:
    • 13 PXIe slots
    • 5 PXI slots
  • Backplane: The chassis supports both PXIe and PXI module types, offering flexibility for different system configurations.
• Power Supply:
  • Type: Internal power supply
  • Voltage: Provides all necessary power rails for PXIe modules
  • Cooling: Includes internal cooling fans to ensure proper ventilation and thermal management
• Cooling:
  • Type: Internal fan cooling system with optimized airflow for efficient heat dissipation.
• Operating Temperature:
  • Temperature Range: 0°C to 55°C (32°F to 131°F)
• Storage Temperature:
  • Storage Range: -40°C to 70°C (-40°F to 158°F)
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing
• Dimensions:
  • Size: 3U height, compact design suitable for both bench-top and rack-mounted configurations.
• Weight:
  • Weight: Approximately 10.9 kg (24 lbs)

Functional Features:

• High-Speed Data Transfer: Supports high-speed PXIe data transfer rates, making it suitable for applications requiring rapid data acquisition and processing.
• Versatile Slot Configuration: Provides a mix of PXIe and PXI slots, allowing for flexible integration of various modules to meet different test and measurement needs.
• Compact and Rugged Design: Designed to be compact yet rugged, it fits well in both laboratory and field settings.
• Built-In Cooling: Equipped with an advanced cooling system to maintain optimal temperatures and ensure the reliability of connected modules.
• Power Management: Features a reliable internal power supply with built-in protection to ensure stable operation of all connected modules.

Application Scenarios:

• Automated Test Systems: Ideal for high-performance automated test systems used in industries such as electronics, telecommunications, automotive, and aerospace.
• Research and Development: Useful in R&D environments where high-speed and high-throughput data acquisition and processing are critical.
• Production Test: Suitable for use in production test environments where reliability and system uptime are crucial.
• Field Testing: Its compact design makes it suitable for portable and field-testing applications.

Additional Considerations:

• Driver and Software Support: Compatible with National Instruments’ software and drivers, including NI LabVIEW, NI MAX, and others, for seamless integration and configuration.
• Integration and Expansion: Facilitates integration with a wide range of PXIe modules and external devices, providing a scalable platform for building complex test systems.
