Technical Specifications:

• Communication Protocols:
  • CAN (Controller Area Network): Supports CAN 2.0A/B
  • LIN (Local Interconnect Network): Supports LIN 2.1
• Number of Channels:
  • CAN Channels: 2
  • LIN Channels: 2
• Data Rates:
  • CAN: Up to 1 Mbps (megabits per second)
  • LIN: Up to 20 kbps (kilobits per second)
• Connector:
  • Type: Typically equipped with automotive or industrial connectors suitable for CAN and LIN networks. Often includes D-Sub or similar connectors for integration.
• Operating Temperature:
  • Temperature Range: 0°C to 55°C
• Storage Temperature:
  • Storage Range: -40°C to 70°C
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing
• Power Requirements:
  • Voltage: Powered by the PXI backplane; no additional external power required.

Functional Features:

• Multi-Protocol Support: Provides simultaneous support for CAN and LIN communication protocols, making it versatile for various automotive and industrial communication needs.
• High-Speed Communication: Offers CAN communication with data rates up to 1 Mbps, suitable for real-time data transfer.
• Flexible Configuration: Supports various configurations for message filtering, error handling, and network monitoring.
• Driver and Software Support: Fully compatible with National Instruments’ software and drivers, including NI LabVIEW and NI MAX, for easy setup, configuration, and control.

Application Scenarios:

• Automotive Testing: Ideal for automotive applications that require testing and validation of CAN and LIN networks, such as in-vehicle diagnostics, communication analysis, and network simulation.
• Industrial Automation: Suitable for industrial systems that use CAN and LIN protocols for communication between devices, sensors, and control systems.
• Embedded Systems: Employed in embedded systems where CAN and LIN protocols are critical for communication and control tasks.

Additional Considerations:

• Driver and Software Integration: Requires National Instruments’ drivers and software for full functionality. Integration with NI LabVIEW and other NI tools is necessary for effective operation.
• Connector and Wiring: Utilizes standard automotive or industrial connectors for CAN and LIN. Proper wiring and signal conditioning are essential to ensure accurate performance and communication.
