Technical Specifications:

• Communication Protocols:
  • CAN (Controller Area Network): Supports CAN 2.0A/B
  • LIN (Local Interconnect Network): Supports LIN 2.1
• Number of Channels:
  • CAN Channels: 2
  • LIN Channels: 1
• Data Rates:
  • CAN: Up to 1 Mbps (megabits per second)
  • LIN: Up to 20 kbps (kilobits per second)
• Connector:
  • Type: Standard automotive or industrial connectors for CAN and LIN, often with D-Sub or other specific connectors for the application.
• Operating Temperature:
  • Temperature Range: 0°C to 55°C
• Storage Temperature:
  • Storage Range: -40°C to 70°C
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing
• Power Requirements:
  • Voltage: Powered by the PXI backplane, no additional external power required.

Functional Features:

• Multi-Protocol Support: Provides support for both CAN and LIN communication protocols, making it versatile for various automotive and industrial applications.
• High-Speed Communication: Offers high-speed CAN communication with data rates up to 1 Mbps, suitable for real-time data transfer and processing.
• Flexible Configuration: Can be configured for different communication scenarios, including message filtering and error handling.
• Driver and Software Support: Compatible with National Instruments’ software and drivers, such as NI LabVIEW, NI MAX, and the NI-CAN and NI-LIN drivers for configuration and control.

Application Scenarios:

• Automotive Testing: Ideal for testing and validating automotive communication systems that use CAN and LIN protocols. Useful for in-vehicle diagnostics and network analysis.
• Industrial Automation: Suitable for applications in industrial environments where CAN and LIN networks are used for control and monitoring purposes.
• Embedded Systems: Employed in embedded systems where CAN or LIN communication is integral to the system’s operation and control.

Additional Considerations:

• Driver and Software Integration: Requires National Instruments’ drivers and software for full functionality and integration into test systems.
• Connector and Wiring: Uses standard automotive or industrial connectors for interfacing with CAN and LIN networks. Proper wiring and signal conditioning are essential for accurate communication and performance.
