Technical Specifications:

• Number of Channels:
  • Analog Output Channels: 16
• Resolution:
  • DAC Resolution: 16 bits
• Output Voltage Range:
  • Range: ±10 V (differential) or 0 to 10 V (single-ended)
• Output Current:
  • Drive Capability: Typically 5 mA per channel
• Update Rate:
  • Max Update Rate: 1 MHz per channel
• Accuracy:
  • Total Unadjusted Error: ±0.01% of full scale
• Connector:
  • Type: 68-pin D-Sub (HD-68) connector
• Operating Temperature:
  • Temperature Range: 0°C to 55°C
• Storage Temperature:
  • Storage Range: -40°C to 70°C
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing

Functional Features:

• High-Resolution Analog Output: Offers 16-bit resolution for precise analog signal generation, ensuring high accuracy and detail in output signals.
• Multiple Output Channels: Provides 16 independent analog output channels, enabling simultaneous signal generation across multiple channels.
• Wide Voltage Range: Capable of outputting voltages from ±10 V (differential) or 0 to 10 V (single-ended), suitable for various applications.
• High-Speed Operation: Supports an update rate of up to 1 MHz per channel, ideal for applications requiring rapid signal changes.
• Accuracy and Stability: Delivers high accuracy with a total unadjusted error of ±0.01% of full scale, ensuring reliable performance in precision tasks.

Application Scenarios:

• Automated Test Systems: Ideal for automated test environments where precise analog signal generation is needed for testing and calibration of electronic devices.
• Signal Simulation: Useful for simulating analog signals in testing scenarios, such as in electronics testing, system validation, and research applications.
• Control Systems: Employed in control systems for generating accurate analog outputs to control external devices or processes.
• Data Acquisition: Suitable for applications requiring high-speed and accurate analog signal generation for data acquisition and analysis.

Additional Considerations:

• Driver and Software Integration: Compatible with National Instruments’ software and drivers, including NI LabVIEW and NI MAX, for easy setup and integration into test systems.
• Connector and Wiring: Utilizes a 68-pin D-Sub connector for interfacing with external equipment. Proper wiring and signal conditioning are essential for optimal performance and accuracy.
