Technical Specifications:

• Number of Channels:
  • Analog Output Channels: 16
• Resolution:
  • DAC Resolution: 16 bits
• Output Voltage Range:
  • Range: ±10 V (differential) or 0 to 10 V (single-ended)
• Output Current:
  • Drive Capability: Typically 5 mA per channel
• Update Rate:
  • Max Update Rate: 1 MHz per channel
• Accuracy:
  • Total Unadjusted Error: ±0.01% of full scale
• Connector:
  • Type: 68-pin D-Sub (HD-68) connector
• Operating Temperature:
  • Temperature Range: 0°C to 55°C
• Storage Temperature:
  • Storage Range: -40°C to 70°C
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing

Functional Features:

• High-Resolution Analog Output: Provides 16-bit resolution for precise analog signal generation, ensuring high accuracy and fidelity in output signals.
• Multiple Output Channels: Offers 16 independent analog output channels, allowing for simultaneous signal generation across multiple channels.
• Wide Voltage Range: Capable of outputting voltages from ±10 V (differential) or 0 to 10 V (single-ended), making it suitable for a variety of applications.
• High-Speed Operation: Supports an update rate of up to 1 MHz per channel, ideal for high-speed signal generation tasks.
• Accuracy and Stability: Provides high accuracy with a total unadjusted error of ±0.01% of full scale, ensuring reliable signal performance.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated test systems requiring precise and simultaneous analog signal generation for testing and measurement purposes.
• Signal Simulation: Useful for simulating analog signals in test environments, such as in electronics testing and system validation.
• Control Systems: Employed in control systems where accurate analog output is necessary for controlling external devices or systems.
• Data Acquisition: Suitable for applications needing high-speed and accurate analog signal generation in data acquisition systems.

Additional Considerations:

• Driver and Software Integration: Integrates with National Instruments’ software and drivers, such as NI LabVIEW and NI MAX, for easy configuration and control.
• Connector and Wiring: Uses a 68-pin D-Sub connector for interfacing with external equipment. Proper wiring and signal conditioning may be required to ensure accurate signal handling and performance.
