Technical Specifications:

• Number of Channels:
  • Digital Lines: 32
• I/O Type:
  • Bidirectional: Each line can be configured as either an input or an output.
• Digital I/O Voltage Levels:
  • Logic Levels: 0 V (low) to 5 V (high), TTL compatible
• Input Characteristics:
  • Input Logic Levels: 0 V to 5 V
  • Input Pull-Up/Pull-Down Resistors: Programmable per channel
• Output Characteristics:
  • Output Drive Capability: Typically 24 mA per line (source and sink)
  • Output Logic Levels: 0 V (low) to 5 V (high)
• Timing Specifications:
  • Update Rate: Up to 1 MHz (for static I/O operations)
• Isolation:
  • Channel-to-Channel Isolation: Not provided; uses common ground.
• Connector:
  • Type: 68-pin D-Sub (HD-68) connector
• Operating Temperature:
  • Temperature Range: 0°C to 55°C
• Storage Temperature:
  • Storage Range: -40°C to 70°C
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing

Functional Features:

• High-Density Digital I/O: Provides 32 digital I/O lines, offering high-density connectivity for digital signal processing in a compact PXI module.
• Flexible I/O Configuration: Each digital line can be individually configured as an input or output, allowing for versatile signal handling and control.
• TTL Compatibility: Operates with standard TTL logic levels, making it compatible with a wide range of digital devices and circuits.
• Programmable Pull-Up/Pull-Down Resistors: Supports customization of input lines to handle different signal conditions effectively.
• High-Speed Operation: Capable of high-speed digital operations with an update rate of up to 1 MHz, suitable for real-time data acquisition and control.
• Driver and Software Support: Compatible with National Instruments’ software and drivers, including NI LabVIEW and NI MAX, facilitating configuration and integration into test systems.

Application Scenarios:

• Automated Test Systems: Ideal for integration into automated test environments where high-density digital I/O is required for device control and monitoring.
• Digital Signal Processing: Useful for applications requiring the handling of multiple digital signals, such as in communication systems and electronic testing.
• Control Systems: Suitable for control systems where switching and controlling digital devices or circuits is necessary.
• Data Acquisition: Employed in data acquisition systems where digital I/O capabilities are needed for capturing and generating digital signals.

Additional Considerations:

• Driver and Software Integration: Requires National Instruments’ drivers and software tools like NI LabVIEW or NI TestStand for complete functionality and system integration.
• Connector and Wiring: Utilizes a 68-pin D-Sub connector for interfacing with external equipment. Proper wiring and signal conditioning may be required for accurate signal handling.
