Technical Specifications:

• Channels:
  • Number of Channels: 4
• Sampling Rate:
  • Maximum Sampling Rate: 500 MS/s per channel
• Bandwidth:
  • Bandwidth: 100 MHz (±3 dB)
• Resolution:
  • ADC Resolution: 14 bits
• Input Range:
  • Voltage Range: ±10 V
• Dynamic Range:
  • Signal-to-Noise Ratio (SNR): 68 dB at full scale
• Input Coupling:
  • Coupling Types: AC and DC
• Acquisition Modes:
  • Modes: Single-shot, multi-shot, and streaming modes
• Triggering:
  • Trigger Types: Edge, pulse width, and digital triggering
• Memory:
  • Onboard Memory: 256 MB per channel
• Timebase Accuracy:
  • Timebase Stability: 50 ppm
• Operating Temperature:
  • Temperature Range: 0°C to 55°C
• Storage Temperature:
  • Storage Range: -40°C to 70°C
• Relative Humidity:
  • Humidity Range: 10% to 90% non-condensing

Functional Features:

• High-Speed Data Acquisition: Capable of acquiring data at up to 500 MS/s per channel, making it suitable for high-speed signal analysis and measurements.
• High Resolution: Provides 14-bit resolution for accurate and detailed signal capture.
• Wide Bandwidth: With a bandwidth of 100 MHz, it can capture a broad range of signal frequencies.
• Flexible Triggering: Offers various triggering options, including edge, pulse width, and digital triggers, to capture specific events in your signals.
• Large Onboard Memory: Equipped with 256 MB of onboard memory per channel, allowing for extensive data capture and analysis.
• Versatile Acquisition Modes: Supports multiple acquisition modes such as single-shot, multi-shot, and streaming, making it adaptable to different testing requirements.

Application Scenarios:

• Signal Analysis: Suitable for capturing and analyzing high-speed signals in various fields such as communications, electronics, and scientific research.
• Automated Test Systems: Ideal for integration into automated test systems where high-speed and high-resolution data acquisition is required.
• Instrumentation: Useful in instrumentation applications where precise and high-speed data capture is critical.
• Research and Development: Employed in R&D environments for detailed signal analysis and experimentation.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Configuration: Integrates seamlessly with other PXI modules and systems, providing a comprehensive solution for high-speed data acquisition.
