Technical Specifications:

• Measurement Functions:
  • DC Voltage: 10 µV to 1000 V
  • AC Voltage: 10 µV to 1000 V (with True RMS)
  • DC Current: 10 nA to 10 A
  • AC Current: 10 nA to 10 A (with True RMS)
  • Resistance: 1 Ω to 100 MΩ
  • Frequency: 1 Hz to 10 MHz
  • Period: 1 µs to 10 s
  • Capacitance: 1 nF to 100 µF
  • Temperature: -200°C to 1820°C (using thermocouples)
• Accuracy:
  • DC Voltage: ±0.01% (basic)
  • DC Current: ±0.05% (basic)
  • Resistance: ±0.02% (basic)
  • Frequency: ±0.02% (basic)
• Resolution:
  • DC Voltage: 6½ digits
  • DC Current: 6½ digits
  • Resistance: 6½ digits
  • Frequency: 6½ digits
  • Capacitance: 6½ digits
• Sample Rate: Up to 100,000 readings per second
• Input Protection:
  • DC Voltage: 1000 V (max)
  • DC Current: 10 A (max)
  • Resistance: 1000 V (max)
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High Accuracy and Resolution: Provides precise measurements with high resolution, making it suitable for demanding applications that require accurate data.
• Wide Measurement Range: Capable of measuring a broad range of signals, including voltage, current, resistance, frequency, and capacitance.
• True RMS Measurement: Supports True RMS measurement for accurate AC voltage and current readings, even for non-sinusoidal waveforms.
• Fast Sampling Rate: Capable of high-speed data acquisition with a sample rate of up to 100,000 readings per second.
• Programmable Features: Offers programmable settings for automated testing and data collection, which can be controlled via National Instruments’ software tools like NI LabVIEW.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated test systems requiring precise and high-speed measurements of electrical signals.
• Electronics Manufacturing: Suitable for testing and validating electronic components and assemblies during manufacturing.
• Research and Development: Useful for experimental setups and development projects where accurate measurement of electrical signals is critical.
• Calibration and Maintenance: Employed in calibration laboratories and maintenance applications where precision and reliability are essential.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Configuration: Easily integrates with other PXI modules and systems, providing a flexible and comprehensive measurement solution.
