Technical Specifications:

• Switch Type: RF Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 8 x 8 (cross-point matrix switch)
• Switch Type: Electromechanical
• Frequency Range: DC to 26.5 GHz
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 1 A
• Maximum Switching Power: 30 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density RF Matrix Switching: Provides an 8 x 8 matrix configuration, allowing for extensive RF signal routing and switching within a single module.
• Wide Frequency Range: Covers frequencies from DC to 26.5 GHz, making it suitable for a wide range of RF and microwave applications.
• High Power Handling: Manages up to 30 W of power, accommodating diverse testing needs.
• Low Insertion Loss and High Isolation: Ensures minimal signal degradation and high isolation between channels, which is critical for accurate RF measurements.
• Electromechanical Relays: Utilizes electromechanical relays for robust and reliable switching performance in RF applications.

Application Scenarios:

• RF and Microwave Testing: Ideal for use in testing RF and microwave components and systems, where high-frequency signal routing and switching are required.
• Automated Test Systems: Suitable for complex automated RF test setups that need high-density and flexible switching solutions.
• Signal Routing: Facilitates efficient routing of RF signals between multiple components or instruments, enhancing test setup flexibility.
• System Simulation: Useful for simulating RF and microwave circuit configurations and system states during development and testing.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Configuration: Integrated with National Instruments’ software tools, offering ease of setup and operation for RF testing applications.
