Technical Specifications:

• Switch Type: Matrix Switch
• Form Factor: PXI (PCI eXtensions for Instrumentation)
• Channel Count: 64 x 64 (cross-point matrix switch)
• Switch Type: Electromechanical
• Maximum Switching Voltage: 30 V
• Maximum Switching Current: 2 A
• Maximum Switching Power: 60 W
• Contact Resistance: < 0.1 Ω
• Insulation Resistance: > 10^9 Ω
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 70°C
• Relative Humidity: 10% to 90% non-condensing

Functional Features:

• High-Density Matrix Switching: Provides a 64 x 64 matrix switch configuration, allowing for complex and flexible signal routing within a single module.
• High-Current Handling: Capable of switching currents up to 2 A per channel, suitable for high-current applications.
• Low Contact Resistance: Ensures minimal signal loss and high measurement accuracy, which is essential for precision testing.
• Electromechanical Relays: Utilizes reliable electromechanical relays for switching, offering robust performance and durability.
• High Power Handling: Manages up to 60 W of power, making it versatile for various test and measurement scenarios.

Application Scenarios:

• Automated Test Systems: Ideal for use in automated testing environments requiring complex signal routing and high-density switching capabilities.
• System Simulation: Useful for simulating various circuit configurations and system states in research and development settings.
• Signal Routing: Efficiently routes signals between multiple components or instruments, enhancing the flexibility and capability of test setups.
• Measurement and Control: Facilitates the management and switching of numerous test signals, supporting advanced measurement and control applications.

Additional Considerations:

• Driver and Software Support: Requires National Instruments’ drivers and software, such as NI LabVIEW or NI TestStand, for configuration and control. Ensure compatibility with your PXI system’s software environment.
• Integration and Control: Integrated with National Instruments’ software tools for effective setup and operation, providing flexibility and ease of use for complex testing needs.
