Technical Specifications:​ 24 VDC supply with ±10% tolerance; 2.5 W typical power consumption; 16 digital inputs at 24 VDC; 16 digital outputs at 24 VDC, 0.5 A per output; dimensions 130 mm x 72 mm x 60 mm; weight 310 g; operating temperature 0°C to +55°C; storage -25°C to +85°C; humidity 5% to 95% non-condensing.

Function Features:​ Independent 24 V inputs and sourcing/sinking outputs according to system wiring; per-channel status through controller diagnostics where supported; compact DIN rail body; direct connection to PLC and industrial sensors/actuators.

Application Scenarios:​ Machine control and monitoring; robotics I/O; material handling; packaging and labeling; assembly-line discrete control.

Performance Parameters:​ 0.5 A maximum per output channel; 24 VDC input threshold; vibration resistance 5 g at 10 to 150 Hz; shock resistance 30 g at 11 ms.

Material Composition:​ Industrial PCB, flame-retardant module housing, DIN rail clamp, screw or spring terminal block, status indicator components.

Structural Characteristics:​ Rectangular DIN rail module with separated input and output terminals, front status indication, fixed wiring terminals, compact 130 mm width class body.

Working Principles:​ Input devices apply 24 VDC to input channels, which are optically isolated and evaluated by the internal logic; output channels switch 24 VDC loads according to controller commands and internal driver protection.

Installation Requirements:​ Mount on 35 mm DIN rail inside a control cabinet; supply 24 VDC within 21.6 to 26.4 VDC; separate input sensor cables from output load cables where electromagnetic noise is present; torque terminals to the manufacturer specification.

Usage Precautions:​ Do not exceed 0.5 A per output; verify total module current against the 2.5 W supply budget and external power capacity; keep ambient temperature within 0°C to +55°C; check output short-circuit protection settings before connecting inductive loads.
