Technical Specifications:​ Unavailable until manufacturer, product category and nameplate data are confirmed.

Functional Features:​ Unavailable until identification is completed.

Application Scenarios:​ Unavailable until identification is completed.

Materials and Structure:​ Unavailable until identification is completed.

Working Principle:​ Unavailable until identification is completed.

Installation Requirements:​ Provide the product photo, manufacturer logo, category, nameplate voltage/current or wire-label information before installation.

Usage Precautions:​ Do not energize unknown electronic or power components without confirmed ratings. Verify insulation, polarity and load compatibility with the final datasheet.

Identification Required​ 17-107-513-120

Product Name:​ Likely Molex FCT 173107-Series Mixed D-Sub Variant, Exact Suffix Unconfirmed

Overview:​ The code 17-107-513-120 aligns with Molex/FCT 173107-series D-sub mixed-layout connector numbering, but the exact suffix 513-120 was not confirmed in the performed search. If the item is a 173107-series 17W2 connector, it is a mixed-signal/power D-sub used for industrial and communications interfaces.

Technical Specifications:​ 173107-series 17W2 arrangements provide 17 total cavities, commonly 15 signal positions plus 2 power/coax/High-voltage positions depending on insert layout. Shell sizes follow standard D-sub 3-shell 17W2 geometry. Housing resin is PBT; shell is steel with tin or other plating depending on suffix. Mating cycles are 500 for standard FCT housings. Operating temperature for standard FCT D-sub products is -55 to +115 °C. Wire size support depends on contact type and includes 18, 20, 22, 24, 26 and 28 AWG for crimp signal contacts. Ingress rating for unfiltered standard housings is IP20. Gender, contact plating, shell finish and power contact type must be confirmed from the 513-120 suffix.

Functional Features:​ Mixed signal and power in one D-sub shell, panel or cable mounting options, shielded steel shell, polarization to prevent mis-mating, crimp or solder contact options, industrial EMI-resistant interconnect.

Application Scenarios:​ Industrial PCs, D-sub serial and fieldbus interfaces, test equipment, power-plus-signal peripherals, rail and automation panels where combined low-level signal and auxiliary power are required.

Materials and Structure:​ PBT insulator, steel shell, copper-alloy contacts, tin or gold plating depending on configuration, panel flange or cable hood options.

Working Principle:​ Mated male and female shells align pinned and power contacts. Signal contacts transmit data lines; power/coax contacts transmit auxiliary current or special signals. Shell shielding maintains reference ground and reduces electromagnetic interference.

Installation Requirements:​ Confirm gender, mounting style and contact crimp tooling from the Molex 173107 product specification. Use proper insertion/extraction tools. Torque panel screws per D-sub standard. Maintain cable strain relief to avoid contact fatigue.

Usage Precautions:​ Do not exceed contact current and voltage ratings defined by the confirmed insert layout. Verify plating compatibility with the application lifecycle. Keep unmated connectors in protective caps when used in IP20 environments.
