Technical Specifications
Dew point range: -100 to +20 °C
Accuracy: ±2 °C dew point
Response time: T95 5 minutes, dry to wet
Output: 4-20 mA, two-wire
Supply voltage: 12-28 VDC
Load: 250 Ω at 12 V, 500 Ω at 24 V
Operating temperature: -40 to +60 °C
Pressure rating: up to 45 MPa
Flow: 1-5 Nl/min sampling, 0-10 m/s inline
Housing: stainless steel
Dimensions: 132 x 27 mm diameter
Protection: IP66 / NEMA 4
Weight: 150 g
Functional Features
User-configurable dew point or ppmv output
Traceable calibration
Temperature-compensated measurement
Fault signaling via 4 mA / 20 mA / 23 mA outputs
Application Scenarios
Glove box moisture monitoring
Compressed air systems
Dry gas pipelines
Semiconductor and laboratory gas systems
Structure Features
Stainless steel probe body
HDPE or optional 316 stainless steel sensor protection
5/8″-18 UNF process connection
Hirschmann GDS electrical connector
Usage Notes
Install with correct flow direction for inline use.
Avoid mechanical shock to sensor tip.
Use specified sampling sleeve for accurate measurement.
