Technical Specifications​

Up to 8 axes depending on configuration. 32-bit RISC processor. Differential encoder inputs with high resolution. Analog inputs 4 channels, 12-bit. Digital I/O 16 inputs and 16 outputs. Communication Ethernet, RS-232, RS-485, USB.

Functional Features​

Multi-axis interpolation. High-speed encoder capture. Programmable I/O. Ethernet and serial communication. PID motion control with filtering and feedforward.

Application Scenarios​

Multi-axis machine automation. Robotic positioning. Precision stage control. Packaging and converting equipment. Research and development motion systems.

Performance Parameters​

Suitable for coordinated multi-axis trajectories. Supports differential encoder feedback for noise immunity.

Material And Structure​

Controller board or box-style unit. Encoder, I/O, communication, and power connectors. Industrial-grade electronics.

Working Principle​

Reads encoder or feedback signals, executes stored motion programs, calculates control outputs, and commands servo/stepper drives over analog, pulse, or communication interfaces.

Installation Requirements​

Mount in controlled electrical cabinet. Use differential encoder cabling for long distances. Ground shield properly. Configure axes, I/O, and network addresses before run.

Usage Precautions​

Confirm exact Galil series and firmware. Do not mix DMC-18xx and DMC-40xx/DMC-41xx wiring blindly. Validate homing and limit logic before automatic motion.
