Technical Specifications
Models: E1100-5M-2X, E1100-8M-2X, E1100-8M-2XG, E1100-16M, E1100-5MP-2X, E1100-8MP-2X, E1100-16MP
Ports: 5 / 8 / 16 Gigabit Ethernet ports
Uplinks: 10G SFP+ or 10G RJ45
PoE Models: Full PoE / PoE+ ports
PoE Budget: Up to approximately 290 W depending on model
Switching Capacity: 65–80 Gbps
MAC Table: Up to 8000 entries
Packet Buffer: Up to 1.5 MB
Input Power: 100–240 V AC, 50/60 Hz
Operating Temperature: 0 °C to 55 °C
Surge Protection: ±4 kV
Mounting: Desktop, rack, or wall-mount
Functional Features
Store-and-forward switching
Energy Efficient Ethernet
PoE for IP cameras, phones, and access points
LED status indicators
Fan-less or managed cooling depending on model
Application Scenarios
Office networks
IP surveillance
Wireless access point powering
Small industrial LANs
Campus edge switching
Structural Characteristics
Metal or desktop/Rack-mount enclosure
LED indicators for link, activity, PoE, power
SFP+ uplink cages
RJ45 PoE ports
Installation Requirements
Use CAT5e or better copper cabling
Ensure PoE load does not exceed power budget
Provide adequate ventilation
Rack-mount with proper grounding
Usage Notes
Do not mix incompatible power modules
Avoid water, dust, and unstable power
Update firmware from trusted source
Use surge protection in lightning-prone areas
