Applied Materials 1080-01772
Product Name
Industrial Process Control Module
Introduction
Public distributor listings identify 1080-01772 as an Applied Materials industrial process-control module for semiconductor and advanced-manufacturing systems. Original manufacturer datasheet confirmation was not obtained in this search, so all parameters below should be verified against the Applied Materials nameplate and system manual.
Detailed content
Technical Specifications
Manufacturer per public listing: Applied Materials
Part number: 1080-01772
Product type: industrial process control module
Power: 24 VDC ±10% in public listing
Communication: Ethernet/IP and Modbus TCP/IP in public listing
Operating temperature: -10°C to +50°C in public listing
Mounting: 35 mm DIN rail in public listing
Ingress protection: IP20 when mounted in cabinet in public listing
Dimensions: 145 mm x 100 mm x 35 mm in public listing
Weight: 0.4 kg in public listing
Interfaces in public listing: analog inputs 4 to 20 mA, digital outputs, Ethernet port
Compliance in public listing: CE, RoHS, SEMI S2/S8
Function Features
Regulates process variables such as gas flow, temperature, or pressure in fab tools, provides analog and digital interfacing, logs process trends in public listing, and integrates with DCS or third-party I/O architectures.
Material Composition
Industrial control-board assembly with metal or molded enclosure suitable for cabinet mounting; exact chassis, connector plating, and internal component grades must be confirmed from the OEM manual.
Working Principle
The module receives process sensor signals, executes control algorithms, drives analog or digital outputs, and communicates setpoints or status over Ethernet/IP or Modbus TCP/IP to the host tool controller.
Application Scenarios
Semiconductor wafer fabrication, CVD or etch reactor control, thin-film deposition, vacuum furnace supervision, solar panel manufacturing, and aerospace high-temperature process support where precise parameter regulation is required.
Installation Requirements
Mount in a cleanroom-grade control cabinet on 35 mm DIN rail where specified. Supply regulated 24 VDC within ±10%. Separate analog sensor wiring from high-power and RF lines. Confirm Ethernet network addressing before integration.
Usage Notes
Verify the exact AMAT tool compatibility before replacement because process-control firmware and I/O mapping vary by platform. Perform calibration and trend-log review after installation. Follow SEMI safety and local electrical rules for fab cabinets.
