Technical Specifications:

• Net Total Capacity: 177 Liters
• Refrigerator Compartment: 134 Liters
• Freezer Compartment (4-star): 43 Liters
• Energy Efficiency Class: A++
• Annual Energy Consumption: 156 kWh/year
• Noise Level: 35 dB(A)
• Climate Class: SN-T / SN-ST
• Temperature Range (Fridge): +2°C to +8°C
• Temperature Range (Freezer): -18°C to -24°C
• Voltage / Frequency: 220-240V / 50Hz
• Power Rating: 95W

Dimensions (W x D x H): 540 x 549 x 820 mm

Material Composition:

• Exterior: White powder-coated steel
• Interior: White ABS plastic liner
• Shelving: 3 toughened glass shelves (2 adjustable + 1 fixed)
• Crisper: 1 transparent drawer with humidity control
• Door Seal: PVC with antibacterial additive (Ag+)
• Freezer Drawer: Transparent front, pull-out

Structural Features:

• Reversible door (left or right opening)
• Automatic defrost (no manual ice removal needed)
• LED interior lighting — energy-efficient, long-life
• 4-star freezer compartment — suitable for frozen food storage up to 12 months
• Adjustable thermostat — mechanical dial control
• Leveling feet — compensates for uneven floors
• Door alarm — audible alert if door left open >60 seconds

Working Principle:
Hermetic reciprocating compressor circulates R600a refrigerant. The evaporator in the refrigerator compartment absorbs heat, cooling the interior. A fan circulates cold air evenly. The freezer compartment uses a separate evaporator coil at lower temperature. Automatic defrost activates a heating element periodically to melt frost buildup on the evaporator.

Key Advantages:

• A++ energy efficiency — low operating cost
• Antibacterial door seal — prevents mold and odor
• Reversible door — flexible installation
• 4-star freezer — reliable frozen food preservation
• 35 dB(A) ultra-quiet — suitable for open-plan living
• LED lighting — bright, cool, energy-saving

Applicable Industries / Use Cases:
Kitchen integration, hotel rooms, serviced apartments, office kitchens

Installation Requirements:

• Cut-out: 540 x 549 x 820mm (W x D x H)
• Requires 10A grounded power outlet
• Minimum 10mm rear clearance for compressor ventilation
• Must be placed on a level, load-bearing floor
• Door swing must not be obstructed by adjacent cabinets

Usage Precautions:

• Allow 24 hours standing time after transport before switching on
• Do not place hot food directly inside — let it cool first
• Clean spills immediately to prevent odor absorption
• Check door seal annually for cracks or damage
• Do not block rear ventilation grille
