Model Series: AS-C951 Series

Type: Indoor Wall-Mounted Unit (requires matching outdoor unit)

Cooling Capacity: 3.5 kW (11,944 BTU/h)

Heating Capacity: 4.0 kW (13,648 BTU/h)

Energy Efficiency Class: A++ (Cooling) / A+ (Heating)

Refrigerant: R-32 (580 g charge)

SEER: 7.9

SCOP: 4.4

Airflow Rate: 680 m³/h (max)

Indoor Noise Level: 21 dB(A) (low) / 40 dB(A) (high)

Power Supply: 220-240V / 50Hz / 1-phase

Rated Input Power (Cooling): 1,020 W

Rated Input Power (Heating): 1,100 W

Dimensions (W x H x D): 890 mm x 295 mm x 200 mm

Net Weight: 10.8 kg

Structure Features:

• Slim wall-mounted design (200 mm depth)
• White glossy front panel
• 3-way air swing (up/down + left/right)
• Washable air filter (access from front)
• LED temperature display (7-segment, hidden)

Function Features:

• Inverter Compressor for variable capacity output
• Silent Operation at 21 dB(A)
• Turbo Mode for fast cooling/heating
• Sleep Mode with auto temperature rise
• Dehumidification Mode
• Timer Function (24-hour)
• Auto Restart
• Self-Cleaning Function (internal evaporator dry)

Installation Requirements:

• Wall-mounted at 2.0–2.8 m from floor
• 16A dedicated circuit with earth leakage protection
• Refrigerant line: liquid Ø 6.35 mm, gas Ø 12.7 mm
• Condensate drain Ø 16 mm with 1% slope
• Outdoor unit: matching AEG AS-C951 variant
