AEG AS-B838-032
Model Series: AS-B838 Series — Standard Inverter Split System
Product Description:
The AEG AS-B838-032 is a wall-mounted indoor AC unit offering reliable cooling and heating with inverter compressor technology. It targets medium-sized rooms with an A+ energy rating and includes a 24-hour timer, turbo mode, and quiet operation.
Detailed content
Technical Specifications:
- Cooling Capacity: 2.0 kW (6,800 BTU/h)
- Heating Capacity: 2.2 kW (7,500 BTU/h)
- Energy Efficiency Ratio (SEER): 5.1 (A+)
- Energy Efficiency Ratio (SCOP): 3.6 (A)
- Refrigerant Type: R410A
- Indoor Noise Level: 24 dB(A) (low) to 38 dB(A) (high)
- Airflow Rate: 520 m³/h
- Dehumidification Capacity: 0.9 L/h
- Voltage / Frequency: 220-240V / 50Hz
- Indoor Unit Power Consumption (Cooling): 590W
- Indoor Unit Power Consumption (Heating): 650W
Dimensions (W x D x H): 790 x 265 x 185 mm
Weight (Indoor Unit): 9.0 kg
Material Composition:
- Casing: White ABS plastic
- Heat Exchanger: Copper and aluminum
- Air Filter: Removable washable mesh
- Louvers: Motorized ABS swing louvers
Structural Features:
- 24-hour on/off timer
- Turbo mode for rapid temperature change
- Quiet mode — limits fan speed to 24 dB(A)
- Auto-restart after power interruption
- Dry mode — dehumidification without overcooling
- Gold fin anti-corrosion heat exchanger
Working Principle:
Inverter-driven compressor adjusts rotational speed to precisely match thermal load. In cooling mode, warm indoor air passes over the cold evaporator coil, moisture condenses and drains away, and cooled air is recirculated. In heating mode, the cycle reverses (heat pump operation).
Key Advantages:
- A+ rated efficiency with inverter compressor
- Turbo mode delivers full capacity within seconds
- Quiet mode at 24 dB(A) for undisturbed sleep
- 24-hour timer for automated scheduling
- R410A refrigerant — zero ODP, stable performance
- Dry mode ideal for humid climates
Applicable Industries / Use Cases:
Bedrooms, study rooms, small offices, rental apartments, boutiques
Installation Requirements:
- Pair with compatible AEG outdoor unit (AS-B838-031 or equivalent)
- Wall must support minimum 18 kg
- Max pipe length: 15m; max height difference: 10m
- 16A circuit with RCD/RCBO protection required
- Condensate drain with 1% downward slope mandatory
- Professional vacuum pump evacuation required
Usage Precautions:
- Wash filters every 2-4 weeks
- Do not block air intake or outlet
- Annual professional service recommended
- Do not operate with damaged power cord
- Keep outdoor unit clear of debris and vegetation
