AEG 416NHM21200
Product Type: Freestanding Refrigerator-Freezer (Bottom-Mount Configuration)
Overview:
The AEG 416NHM21200 is a freestanding bottom-mount refrigerator from the Santo series, combining NoFrost technology with multi-airflow cooling for consistent temperature distribution and long-term food preservation.
Detailed content
Technical Specifications:
- Total Gross Capacity: 346 Litres
- Refrigerator Compartment: 230 Litres
- Freezer Compartment: 116 Litres
- Energy Efficiency Class: A++
- Annual Energy Consumption: 265 kWh
- Noise Level: 39 dB(A)
- Climate Class: SN-T (10°C to 43°C ambient)
- Dimensions (H x W x D): 1,850 mm x 600 mm x 650 mm
- Voltage: 220-240 V / 50 Hz
- Colour: Stainless Steel Finish
Key Features:
- NoFrost Technology: Automatic defrost prevents ice build-up in the freezer — no manual defrosting required
- AirFlow Multi-Zone Cooling: Even air distribution across all compartments maintains consistent temperature
- FastFreeze Function: Rapidly lowers freezer temperature to -24°C to lock in nutrients and freshness
- Temperature Alarm: Audible alert if internal temperature rises above safe levels
- Door Open Alarm: Audible warning if door remains open for too long
- Egg Holder: Dedicated egg tray in the refrigerator door
- Adjustable Glass Shelves: Spill-proof tempered glass, repositionable
- VitaFreshPro Crisper Drawer: Humidity-controlled drawer for fruits and vegetables
- Reversible Door Hinge: Door can be repositioned for left or right opening
Working Principle:
Uses a hermetically sealed compressor with R600a (isobutane) refrigerant. The compressor circulates refrigerant through the evaporator, absorbing heat from the interior and releasing it externally via the condenser. The NoFrost system uses a heated evaporator to automatically evaporate any frost build-up.
Installation Requirements:
- Freestanding unit — place on a flat, level, load-bearing floor
- Minimum 5 cm clearance at the rear for ventilation
- Minimum 2 cm clearance on each side
- Do not install in direct sunlight or near heat sources
- Level using adjustable front feet
- Allow 24 hours standing upright before switching on after transport
Usage Notes:
- Allow the appliance to stand for 24 hours before first use
- Do not block the rear ventilation grille
- Clean condenser coils every 6 months
- Wipe spills immediately to prevent odour
- Set freezer to -18°C and refrigerator to 4°C for optimal food preservation
