Woodward A8251-323
- Product Name: EG‑Series Proportional Actuator (EG‑3P/EG‑6P)
- Product Description: A high‑precision electro‑hydraulic proportional actuator that converts electrical control signals into mechanical rotary motion, designed for fuel/steam valve control in engines and turbines.
- Technical Specifications:
- Input Signal: 4–20 mA DC (standard control signal)
Detailed content
-
- Output Torque: Up to 60 Nm (high torque for heavy‑duty valves)
- Rotation Angle: 0–90° (adjustable mechanical stop)
- Power Supply: 24 V DC
- Operating Temperature: -40°C to +85°C
- Weight: ~16 kg
- Mounting: Vertical or horizontal installation
- Key Features:
- Precise proportional control of fuel/steam flow
- Integrated hydraulic amplifier for high force output
- Sealed oil‑filled design for long‑term reliability
- Compatible with Woodward 2301A, 723PLUS, and 505 controllers
- Hardened moving parts for extended service life
- Applications:
- Diesel/gas engines and steam/gas turbines
- Generator sets, pumps, compressors, and industrial machinery
- Prime mover fuel valve and throttle control systems
