Woodward 5464-017
Product Name: NetCon 5000 Series Main CPU Control Module
Product Overview: Industrial grade redundant central processing unit module, core control core for Woodward NetCon distributed control system, dedicated for turbine, generator and prime mover integrated control, undertakes real-time logic operation, analog/digital signal acquisition, interlock protection and network communication scheduling, fully compatible with NetCon system rack installation.
Detailed content
Technical Specifications
- Architecture: 32-bit RISC industrial dedicated processor
- Operating Power: 5VDC standard backplane power supply
- Working Ambient Temperature: -40°C ~ +85°C
- Storage Temperature: -55°C ~ +100°C
- Humidity Range: 5%~95% non-condensing
- Installation Method: Standard DIN rail / chassis plug-in installation
- Communication Interface: Onboard industrial fieldbus interface, support system internal high-speed data exchange
- Isolation Level: Full electrical isolation between input, output and power port
Functional Features
- Support hot swap online replacement, no system shutdown during module maintenance
- Built-in hardware watchdog circuit, automatic fault reset and operation protection
- Adopt anti-interference electromagnetic design, adapt to strong electromagnetic interference industrial site
- Integrated self-diagnosis function, real-time upload module operating status, fault code and alarm information
- Support redundant backup operation, main and standby CPU automatic switching without disturbance
Application Scenarios
- Steam turbine, gas turbine, hydro turbine centralized control system
- Thermal power plant, combined cycle power generation unit automation control
- Oil & gas compressor unit, pipeline pressurization station prime mover control
- Industrial large engine speed regulation, load distribution and interlock protection system
