Manufacturer:WINGREEN

Model:IPB PCB

Version:V2.0_A01

Product Type:Industrial Control Module

Form Factor:PCB

Dimensions:10cm x 15cm x 2cm

Weight:0.5kg

Input Voltage Range:12V – 24V DC

Operating Temperature Range:-20°C to +70°C

Communication Protocol:Modbus TCP/IP

Control Inputs:8 Digital Inputs

Control Outputs:4 Relays

Power Consumption:10W Max

Certifications:CE, RoHS Compliant

    The WINGREEN IPB PCB V2.0_A01 is designed for demanding industrial environments, ensuring robust performance and reliability. Its advanced circuit design supports a wide range of input and output channels, making it suitable for complex control systems.

    This module features an innovative PCB layout that minimizes electromagnetic interference (EMI), providing stable and accurate data acquisition and control signals. The compact size allows for easy integration into existing machinery and systems.

    The WINGREEN IPB PCB V2.0_A01 supports multiple communication protocols, including Modbus RTU and CAN Bus, enabling seamless integration with various industrial control systems and devices. This flexibility ensures compatibility with different automation platforms.

    With a wide operating temperature range from -20°C to +70°C and a humidity range up to 95%, this module can withstand harsh industrial conditions without compromising performance. Additionally, it has been certified to meet CE, RoHS, and UL standards, ensuring safety and compliance in global markets.

    Installation and maintenance are straightforward due to its intuitive design and clear labeling. The user manual provides comprehensive guidance on setup, operation, and troubleshooting, making it easy for users to get started quickly.
