Vishay 120NQ045R – High-Quality Power MOSFET for Industrial Control Applications
The VISHAY 120NQ045R is a high-performance N-channel power MOSFET designed for efficient switching applications in industrial control systems. It offers low on-state resistance and fast switching speeds, making it ideal for use in various power electronics and automation equipment.
Detailed content
Manufacturer:Vishay
Model Number:120NQ045R
Type:Power MOSFET
Voltage Rating:450V
Current Rating:120A
On-State Resistance (Rds(on)):13.5mΩ
Gate Charge (Qg):125nC
Package Type:TO-247
Thermal Resistance (θJA):0.8°C/W
Max Junction Temperature (Tjmax):175°C
Capacitance Parameters:Ciss, Coss, Crss
The Vishay 120NQ045R is engineered for demanding industrial environments where reliability and precision are paramount. Its robust construction ensures long-term stability and minimal drift over time.
With a power rating of 120 watts and a resistance value of 45 ohms, this resistor is well-suited for applications requiring high energy dissipation and precise resistance control.
The resistor features a temperature coefficient of ±25 ppm/°C, ensuring consistent performance across a wide range of temperatures from -55°C to +155°C.
Its screw terminal termination type provides secure and reliable connections, making it ideal for integration into industrial control systems and machinery.
The Vishay 120NQ045R is compliant with international standards and certifications, ensuring it meets the highest quality and safety requirements.
