Technical Specifications

• Model Number: VM600 IOC4T
• Channels: 4 dynamic signal inputs and 2 tachometer (speed) inputs
• Connectors: 48-terminal screw terminal connectors for I/O connections
• Relays: 4 configurable relays for alarm signals
• Outputs: 32 fully programmable open-collector outputs
• EMI Protection: Provided for all inputs and outputs
• Hot-swappable: Allows for card replacement or maintenance without system downtime
• Operating Voltage: 24Vdc/120Vac
• Operating Frequency: 50/60Hz

Functional Characteristics

• High Reliability: Designed with EMI protection and screw terminal connectors for稳固可靠的connections.
• Flexibility: Supports 4 dynamic channels and 2 tachometer channels, all independently configurable.
• Programmable Outputs: Features 32 programmable open-collector outputs that can be jumper-selected to IRC4 and RLC16 relay cards.
• Real-time Monitoring: Capable of real-time monitoring and protection, with software-controlled relays for alarm signals.
• Hot-swappable: Enables easy card replacement or maintenance during operation.

Application Scenarios

The Vibro-meter VM600 IOC4T is ideal for a wide range of industrial applications that require precise monitoring and protection of machinery. It is commonly used in:

• Machine Monitoring: For continuous monitoring of machine vibration and speed to prevent unexpected failures.
• Industrial Automation: In automated systems where real-time data on machine status is crucial for efficient operation.
• Predictive Maintenance: To collect data for predictive maintenance, helping to extend the lifespan of equipment and reduce downtime.
• Safety-critical Applications: In applications where the failure of machinery could lead to significant consequences, the VM600 IOC4T provides an essential layer of protection.
