Model:TBS1152B

Type:Digital Storage Oscilloscope

Display:10.1-inch color LCD touch screen

Sample Rate:5 GS/s

Maximum Bandwidth:200 MHz

Channel Capacity:2 channels

Input Impedance:1 MΩ

Trigger Modes:Edge, Pulse, Video, and Pattern

Memory Depth:2 Mpts/channel

Power Supply:AC or internal Li-ion battery

Dimensions (WxDxH):300 x 300 x 110 mm

Weight:3.8 kg

    The Tektronix TBS1152B Digital Oscilloscope is equipped with a high-speed sampling rate, allowing for precise capture and analysis of complex waveforms. Its robust design ensures reliability in demanding industrial environments.

    With a resolution of 12 bits, it provides detailed signal representation, making it ideal for applications requiring high precision. The oscilloscope’s versatile probe attenuation feature accommodates a wide range of test scenarios, from low to high voltage signals.

    Featuring a large memory depth of 1 Mpts, this oscilloscope can store extensive data sets, facilitating detailed analysis and comprehensive waveform capture. The inclusion of various trigger modes enables users to capture transient events accurately and efficiently.

    User-friendly interface combined with intuitive software features enhance the usability of the TBS1152B, making it accessible to both experienced technicians and new users. Its compatibility with a wide array of test equipment further expands its utility in diverse testing environments.

    Designed with ergonomics in mind, the Tektronix TBS1152B offers comfort during extended use, ensuring that professionals remain productive throughout their workday. The device’s durability and compact size make it suitable for on-site testing and field service applications.
