Tektronix 5A18N Function Generator, High Precision Arbitrary Waveform
The Tektronix 5A18N Arbitrary Function Generator is a versatile tool designed for generating precise waveforms in various industrial applications. Ideal for testing and debugging electronic circuits, this generator offers high accuracy and reliability.
Detailed content
Frequency Range:Up to 20 MHz
Output Amplitude:2 Vpp to 10 Vpp
Waveform Types:Sine, Square, Triangle, Pulse
Frequency Resolution:0.1 Hz
Amplitude Resolution:0.1 Vpp
Signal Purity:≤ -80 dBc @ 1 kHz
The Tektronix 5A18N Function Generator is designed to deliver high precision and reliability in generating a wide range of waveforms. With its advanced signal generation capabilities, it is an essential tool for engineers and researchers working in fields such as electronics, telecommunications, and scientific research.
This model features a frequency range from 1 µHz to 50 MHz, making it suitable for a broad spectrum of applications. The output amplitude can be adjusted between 0.1 Vpp to 10 Vpp, providing flexibility in signal strength configuration.
The generator supports multiple waveform types including sine, square, triangle, ramp, noise, and arbitrary waveforms. This versatility allows users to tailor their signals to meet specific testing and research requirements.
The device incorporates a high-resolution display with a user-friendly interface, enabling easy setup and operation. Additionally, the Tektronix 5A18N comes equipped with USB, LAN, and GPIB interfaces, facilitating seamless integration into modern laboratory environments.
Designed with durability and ease of use in mind, the Tektronix 5A18N Function Generator ensures reliable performance over time. Whether you’re conducting routine tests or complex experiments, this function generator is a valuable asset for any professional lab.
