Schneider Modicon Quantum 140NOC77101 Ethernet Communication Module
The Schneider 140NOC77101 Modicon Ethernet Communication Module is a cutting-edge industrial interface designed for seamless integration into complex control systems, enabling high-speed data transfer and network communication. It supports advanced protocols, ensuring compatibility and efficiency in diverse manufacturing environments.
Detailed content
Extended Product Type:Communication Module
Product ID:140NOC77101
Schneider Type Designation:Modicon Quantum
Product Category:Ethernet Communication
Communication Ports:1 Ethernet Port (10BASE-T/100BASE-TX)
Connector Type:RJ45
Supply Voltage:5V DC via rack
Current Consumption:400mA at 5V DC
Weight:0.76 lb (0.345 kg)
The Schneider 140NOC77101 Ethernet Communication Module is designed for the Modicon Quantum automation platform, ensuring enhanced network performance and reliability.
With its robust Ethernet/IP and Modbus TCP capabilities, this module enables efficient data transfer between diverse industrial systems, facilitating real-time operations and improving productivity.
Equipped with a 10BASE-T/100BASE-TX Ethernet port, the module supports both fast and slow-speed networking, accommodating a wide range of industrial environments.
The use of RJ45 connectors ensures compatibility with standard network cables, simplifying installation and maintenance processes.
Drawing power from the rack supply, the module consumes only 400 mA at 5 V DC, making it energy-efficient and suitable for rack-based systems.
Lightweight at 0.76 lb (0.345 kg), the module is easy to integrate into existing systems without causing additional load.
