Product Model:490NRP25300

Brand:Schneider

Type:Modbus Plus Fiber Optic Repeater

Range:For Modicon Premium/Quantum Automation Platforms

Transmission Support Medium:Fiber Optic

Connector Type:Between Pins

Weight:0.5kg (approx.)

Dimensions:65mm x 22mm x 22mm (LxWxH)

Operating Temperature Range:-40°C to +85°C

Humidity Range:5% to 95% non-condensing

Certifications:CE, RoHS, UL

    The Schneider 490NRP25300MB+ Fiber Optic Repeater is an essential accessory for extending the capabilities of the Modicon Quantum automation platform. It supports reliable, high-speed data transmission over long distances via fiber optic cables, ensuring optimal performance in demanding industrial environments.

    Key Features:

    – Supports Modbus Plus protocol for seamless integration with Modicon Quantum systems.

    – High-performance design ensures minimal signal loss over extended distances.

    – Robust construction withstands harsh industrial conditions.

    – Compact and lightweight, facilitating easy installation and maintenance.

    Application Areas:

    – Industrial Automation

    – Manufacturing Plants

    – Process Control Systems

    – Remote Monitoring Solutions

    Installation Instructions:

    1. Identify the required fiber optic cable length based on the distance between devices.

    2. Connect the fiber optic cable to the appropriate ports on the repeater and the connected device.

    3. Power the repeater using a 24 V DC power supply.

    4. Ensure all connections are secure and the system is properly grounded.

    Compatibility:

    The Schneider 490NRP25300MB+ Fiber Optic Repeater is compatible with various Modicon Quantum modules, making it a versatile choice for a wide range of industrial applications.
