I/O Size:0/120/240 – 16-bit integers

Communication Parameters:Baud Rate: 110 to 115K baud | Stop Bits: 1 or 2 | Data size: 7 or 8 bits | Parity: None, Even, Odd

Floating Point Data Support:Enabling floating point data movement with configurable support for various implementations

Product Model:MVI69E-MBTCP

Module Type:Prosoft PLC Communication Module

    The Prosoft MVI69E-MBTCP Enhanced Communication Module is designed to elevate the performance of industrial automation systems by offering seamless integration with CompactLogix processors. This ASCII module supports the latest 1769 I/O bus capability, ensuring compatibility and enhanced functionality.

    With an add-on instruction feature, the module creates User Defined Types (UDTs), which provide logical definitions for input/output, status, and control data. This ensures streamlined data management and efficient operation within the CompactLogix system.

    Enhanced diagnostic capabilities are available through RSLogix 5000 controller tags, allowing users to make informed decisions based on real-time node health information. This proactive monitoring helps in maintaining optimal system performance.

    Equipped with licensed backplane technology, the module is manufactured under license from Rockwell Automation, ensuring high-speed data transfer between the MVI69 module and CompactLogix/MicroLogix processors. The inclusion of sample ladder logic simplifies setup and integration.

    The Prosoft MVI69E-MBTCP module offers a versatile interface, supporting Modbus Master/Slave protocol. It allows users to emulate either Modbus Master or Slave devices on individual application ports, providing flexibility in various industrial settings.
