. Technical Specifications
• Form-factor: single-slot 1756-style card for ControlLogix rack
• CPU: 32-bit ARM core running Windows CE 5.0
• Memory: 64 MB CompactFlash for OS and user application storage
• Power: 5 VDC @ 1.2 A from backplane; total dissipation 6 W
• Operating temperature: 0 °C to +60 °C
• Dimensions: 145 mm × 35 mm × 127 mm (H × W × D)
• Certifications: CE marked, RoHS compliant, UL listed
Detailed content
2. Functional Features
• On-board real-time operating system enabling custom C/C++ or IEC 61131-3 programs
• Direct register-level access to ControlLogix backplane for high-speed data exchange
• Integrated FTP and web server for remote diagnostics and file transfer
• Dual serial ports (RS-232/RS-485) and one Ethernet 10/100 port for external devices
• Hot-swap capable; insertion/removal under power without rack shutdown
• LED status array for power, CF activity, Ethernet link, and fault indication
• On-board real-time operating system enabling custom C/C++ or IEC 61131-3 programs
• Direct register-level access to ControlLogix backplane for high-speed data exchange
• Integrated FTP and web server for remote diagnostics and file transfer
• Dual serial ports (RS-232/RS-485) and one Ethernet 10/100 port for external devices
• Hot-swap capable; insertion/removal under power without rack shutdown
• LED status array for power, CF activity, Ethernet link, and fault indication
3. Application Scenarios
• High-speed data logging or custom algorithm execution beside standard ladder logic
• Protocol conversion gateway linking Modbus, ASCII, or proprietary serial devices to ControlLogix systems
• Machine-condition monitoring with on-board FFT or statistical analysis
• Recipe management and SQL database interface for batch processing lines
• Vision-system integration where custom image-processing routines run on the card
• High-speed data logging or custom algorithm execution beside standard ladder logic
• Protocol conversion gateway linking Modbus, ASCII, or proprietary serial devices to ControlLogix systems
• Machine-condition monitoring with on-board FFT or statistical analysis
• Recipe management and SQL database interface for batch processing lines
• Vision-system integration where custom image-processing routines run on the card
4. Ordering & Support Package
• 56SAM-810 module pre-loaded with Windows CE image
• Quick-start guide and development toolkit CD (SDK, drivers, sample code)
• Two-year factory warranty and repair service
• 56SAM-810 module pre-loaded with Windows CE image
• Quick-start guide and development toolkit CD (SDK, drivers, sample code)
• Two-year factory warranty and repair service
