Number of Thermocouple Inputs:4

Thermocouple Types Supported:Types J, K

Input Voltage Range:10V to 30V DC

Current Consumption:≤20mA per channel

Operating Temperature:-20°C to 55°C

Power Supply:DC 24V

Dimensions (WxHxD):96mm x 124mm x 101.5mm

Weight:Approx. 0.18kg

    Integrating seamlessly into the CP1W series, the CP1W-8ER I/O expansion module significantly enhances operational flexibility and efficiency in industrial control systems. It supports up to four thermocouples of types J and K, ensuring accurate temperature measurement across a wide range of applications.

    The module is equipped with a robust power supply compatible with DC 24V, ensuring reliable operation under various environmental conditions. Its compact design, featuring dimensions of 125mm x 90mm x 113mm and weighing only 0.2kg, makes it an ideal choice for space-constrained installations.

    Facilitating quick and easy installation via DIN rail mounting, the CP1W-8ER is compatible with a range of OMRON CPUs and I/O units, allowing for modular expansion of your existing control system. This compatibility ensures a seamless integration with your current infrastructure, enhancing its scalability and adaptability.

    Equipped with a communication interface that supports RS-232C, the module is capable of interfacing with other devices and systems through the CompoNet protocol. This enables real-time data exchange and monitoring, crucial for optimizing performance and maintenance schedules.

    Designed with durability and reliability in mind, the CP1W-8ER is rated for operation within the temperature range of -20°C to +60°C. Its sturdy construction ensures long-lasting performance, backed by OMRON‘s commitment to quality and safety standards.
