Moog 304-121A/304121A Servo Valve
Technical Specifications:
- Flow Capacity: Up to 30 liters per minute (depending on system pressure and configuration).
- Pressure Rating: Suitable for systems operating up to 350 bar.
- Response Time: Typically less than 15 milliseconds for full stroke, enabling rapid adjustments.
- Input Signal: Accepts standard ±10 VDC or 4-20 mA control signals for compatibility with various controllers.
- Hysteresis: Less than 2% of rated flow, ensuring minimal dead zone and high accuracy.
Detailed content
- Functional Characteristics:
- High Precision: Utilizes a feedback mechanism to maintain precise control of valve position, minimizing overshoot and undershoot.
- Robust Design: Constructed with high-quality materials to withstand harsh industrial environments, including resistance to corrosion and wear.
- Low Leakage: Optimized valve seat and spool design reduce internal leakage, improving system efficiency.
Application Scenarios: - Metal Processing: Used in rolling mills and extrusion presses for precise thickness and shape control.
- Aerospace: Employed in flight control systems for aircraft and spacecraft for reliable and accurate actuation.
- Power Generation: Controls the position of steam turbine valves for efficient power output regulation.
