Product Name: Metso A413147 BIU8N Module (Analog Input Module)
Product Introduction: The Metso A413147 (BIU8N) is an analog signal acquisition module within the Metso Outotec BIU8 distributed control platform. It collects analog voltage/current signals from field transmitters in mining, mineral processing, and heavy industrial applications, performing high-precision signal conditioning and bus data upload to the main controller.
Detailed content
METSO A413147
Technical Specifications:
|
Parameter
|
Value
|
|---|---|
|
Brand
|
METSO (Metso Outotec)
|
|
Model
|
A413147
|
|
Designation
|
BIU8N
|
|
Product Type
|
Analog Input Module / Control Board
|
|
Channels
|
8 channels (independent signal status LEDs)
|
|
Signal Type
|
Voltage/current (4–20 mA, 0–10 V)
|
|
Isolation
|
Full-channel electrical isolation
|
|
Accuracy
|
±0.05% FS
|
|
Measurement Resolution
|
16-bit A/D conversion
|
|
Communication
|
Modbus RTU / Internal bus protocol
|
|
Operating Temperature
|
-40°C to +60°C
|
|
Front Panel Protection
|
IP65
|
|
Power Supply
|
Regulated 24 V DC (±10%)
|
|
Mounting
|
35 mm DIN rail / Control cabinet
|
Functional Features:
- Full-channel electrical isolation (zero crosstalk between adjacent channels)
- Built-in hardware overvoltage, overcurrent, and reverse power supply protection
- Multi-range signal auto-identification via software configuration
- Real-time channel fault diagnostics (open-circuit/short-circuit/overvoltage)
- Compatible with all standard industrial voltage and current transmitters
- Hot-swap maintenance capability (no full system shutdown required)
- Low-temperature drift circuit design for stable measurement
Material Composition:
- Industrial-grade PCB with conformal coating
- Precision operational amplifiers for signal conditioning
- Optocoupler isolation components
- 16-bit A/D converter chips
- On-board MCU for data processing
Structural Characteristics:
- Compact lightweight design for DCS cabinet space efficiency
- 8-channel independent signal status LED indicators + module power fault indicator
- Internal layered heat dissipation structure with reserved air convection channels
- Anti-vibration positioning buckle on both sides of module
- Fixed locking structure after inserting into backplane
Working Principle:
Field analog signals enter each independent isolation channel through terminal wiring. Optocouplers provide electrical isolation between field side and control bus side to eliminate ground loop interference. Precision operational amplifiers complete signal filtering, amplification, and range adjustment. 16-bit A/D chips convert analog signals into digital data. On-board MCU processes digital data, packages it according to Modbus RTU protocol, and transmits processed measurement data to the Metso BIU8 main control backplane via the internal bus. Real-time self-diagnosis circuits monitor channel open-circuit, short-circuit, and overvoltage faults, outputting alarm signals via front-panel LEDs.
Installation Requirements:
- Install on standard 35 mm DIN guide rail inside Metso BIU8 DCS control cabinet
- Ambient environment must avoid direct sunlight, water splash, and corrosive gas exposure
- Maintain ≥20 mm heat dissipation gap between adjacent modules
- Use shielded twisted-pair cables for field signal wiring
- Cable shield layer must be single-point grounded inside cabinet
- Power supply must use regulated 24 V DC industrial power supply (±10% voltage fluctuation limit)
Usage Notes:
- Strictly prohibit reverse connection of 24 V DC power terminals
- Input signal voltage/current must not exceed maximum allowable range per channel
- Do not disassemble module housing (internal sealing and isolation structure will be damaged)
- Clean front panel LED and terminal dust every 6 months
- Storage environment must remain dry
- After fault alarm, cut off field signal power supply before replacing wiring or module
