METSO A41300
Product Name: Metso Analog Input Module (A41300)
Product Introduction: The Metso A41300 is an analog input module within the Metso/Valmet distributed control system (DCS) architecture. It digitizes standard analog field signals (4–20 mA or 0–10 V) from process sensors into digital process variables for PLC processors and safety controllers.
Detailed content
Technical Specifications:
|
Parameter
|
Value
|
|---|---|
|
Brand
|
METSO (Valmet Automation / Neles)
|
|
Model
|
A41300
|
|
Product Type
|
Analog Input Module
|
|
Channel Capacity
|
8 channels
|
|
Input Signals
|
4–20 mA, 0–10 V DC
|
|
Isolation
|
1500 V (per channel)
|
|
Scan Rate
|
Down to 100 ms per channel
|
|
Power Supply
|
24 V DC (node-supplied)
|
|
Operating Temperature
|
-20°C to +60°C
|
|
Protocol Support
|
Modbus, Profibus, HART (optional)
|
|
Compliance
|
CE, ISO 9001, RoHS
|
Functional Features:
- Per-channel galvanic isolation (up to 1500 V)
- Optional HART overlay for bidirectional device communication
- Onboard diagnostics for wire breaks, overrange, and HART timeouts
- Redundancy support with standby module failover
- EMI shielding for signal integrity in noisy environments
Material Composition:
- Multi-layer FR-4 PCB substrate
- Industrial-grade integrated circuits and precision resistors
- Shielded enclosure for electromagnetic compatibility
Installation Requirements:
- Insert into compatible Metso/Valmet I/O node backplane
- Use shielded twisted-pair cabling for analog loops
- Ground shield at designated single reference point
- Maintain proper cabinet cooling and sealing
Usage Notes:
- Verify external loop power supply matches channel rating
- Tighten terminal screws to manufacturer torque specifications
- Deactivate unused channels in system configuration software
- Use ESD wrist strap when handling internal circuitry
