Manufacturer:MERCURY

Model:C-663

Type:Stepper Motor

Voltage Rating:24V DC

Rated Torque:3 Nm

Step Angle:1.8°

Current per Phase:3.5 A

Resistance per Phase:2 Ohms

Inductance per Phase:10 mH

Inertia:0.01 kg·m²

Operating Temperature Range:-20°C to +70°C

Mounting Flange:NEMA 23

Weight:1.5 kg

    The Mercury Step C-663 Stepper Motor Module is engineered for robust performance in demanding industrial environments. Its 5-phase design ensures smooth operation and high reliability. With a rated torque of 3 Nm and a holding torque of 4 Nm, this stepper motor can handle heavy loads while maintaining precise positioning. The module operates within a voltage range of 12-48V DC, making it compatible with a wide variety of power sources. Each revolution is divided into 200 steps, providing exceptional resolution and accuracy. The frequency range of 0-2000 Hz allows for fast and accurate positioning. Designed with efficiency in mind, the motor consumes minimal power while delivering maximum torque. Its compact size of 150mm x 100mm x 50mm makes it easy to integrate into various machinery and systems. The Mercury Step C-663 Stepper Motor Module is built to last, featuring a durable construction that can withstand the rigors of industrial use. Whether you’re automating a production line or building a robotic system, this stepper motor provides the precision and reliability you need.
