Koyo Automation Direct D2-16ND3-2 DC Input Module for DirectLogic 205 Series
The Koyo D2-16ND3-2 DC Input Module is a versatile component designed for seamless integration with Automation Direct’s DirectLogic 205 programmable logic controller (PLC). Tailored for industrial automation applications, this module offers 16 DC input channels, facilitating efficient signal acquisition and processing.
Detailed content
Model:D2-16ND3-2
Module Type:DC Input Module
Application Category:Automation Direct/DirectLogic 205
Input Points:16
Rated Input Voltage:24 V DC
Input Voltage Range:20 to 28 V DC
Peak Voltage:30.0 V DC
Input Current:Standard 4.0 mA (12 V DC), Maximum 6 mA (28 V DC)
Status Display:Green LED for Module Operation
Commons:2 Isolated
Weight:20 g
Module Size:Dimensions (mm) – W: 60 x L: 95 x H: 45
Engineered for precise signal acquisition, the Koyo Automation Direct D2-16ND3-2 DC Input Module ensures accurate data transfer in demanding industrial environments. With its robust design and wide input voltage range, it is compatible with various control systems.
Each of the 16 input points is equipped with a Green LED indicator for real-time status monitoring, providing immediate feedback on the module’s operational health. The isolation feature between the commons enhances system reliability and prevents potential interference.
Featuring a compact size and lightweight construction, this module is easy to install and integrate into existing automation setups. Its compatibility with the DirectLogic 205 series makes it an ideal choice for enhancing system performance and efficiency.
The D2-16ND3-2 is designed with an operating temperature range of -20°C to +60°C, ensuring stable operation in a wide variety of industrial settings. It also supports storage temperatures from -40°C to +85°C, making it suitable for long-term use in harsh conditions.
To ensure ease of maintenance and flexibility, the module includes a removable terminal. This feature allows for quick access to connections, facilitating troubleshooting and adjustments without the need for additional tools.
