Kollmorgen S61401-PB

Product Overview

S61401-PB is a 14Arms high-performance digital servo drive under Kollmorgen S600 series. Model breakdown: S6 = S600 platform identifier; 14 = 14 Arms continuous three-phase output current rating; 01 = base 208–480V three-phase mains input hardware variant; suffix PB = factory integrated PROFIBUS-DP fieldbus expansion card + sine/cosine incremental encoder dedicated feedback interface configuration.
WhatApp
WeChat

Detailed content

Technical & Performance Specifications

  • Three-Phase Mains Input Voltage: 208–480 VAC (±10%), 50/60Hz industrial grid standard
  • Continuous Per-Phase Output Current: 14 Arms RMS
  • Peak Overload Output Current: 39.2 Arms RMS, sustainable for maximum 5 seconds (280% continuous overload capacity)
  • Nominal DC Bus Intermediate Circuit Voltage: 560–675 VDC, overvoltage protection threshold 900 VDC
  • Control Loop Bandwidth Limit: Maximum 400 Hz velocity loop bandwidth
  • Current Loop Sampling Refresh Rate: 16 kHz (62.5 μs sampling cycle)
  • Position Loop Refresh Rate: 4 kHz (250 μs sampling cycle)
  • Fixed PWM Switching Frequency: 8 kHz, software adjustable to 16 kHz for low-noise operation
  • Onboard Standard Communication: CANopen DS402 protocol, RS232 multi-drop diagnostic serial port
  • Expansion Bus Interface (PB suffix): PROFIBUS-DP fieldbus, 9.6 kbps ~ 12 Mbps adjustable baud rate
  • Feedback Compatibility (PB suffix): 1Vpp sine/cosine incremental encoders, EnDat 2.2, Hiperface, resolvers, single-cable SFD feedback devices
  • Analog I/O Terminals: 2 × ±10VDC differential analog input, 2 × ±10VDC analog output with 10-bit signal resolution
  • Digital I/O Terminals: 8 × 24VDC optical isolated sinking/sourcing input, 4 × 24VDC isolated open-collector output
  • Integrated Hardware: 200W internal dynamic braking resistor, CE-compliant 20A rated mains EMC filter
  • Complete Protection Function Set: Overcurrent, DC bus overvoltage/undervoltage lockout, heatsink overtemperature, motor winding thermal fault, encoder feedback loss, output phase short circuit, earth leakage short circuit, overspeed fault interlock
  • Cooling System: Built-in brushless DC axial fan forced air cooling with removable intake dust filter screen
  • Protection Class: IP20, cabinet internal installation only
  • Net Unit Weight: 4.1 kg
  • Outer Physical Dimensions (W × H × D): 70 mm × 285 mm × 215 mm

Material Composition

  1. Outer Chassis Frame: Cold-rolled galvanized steel sheet coated with matte black electrostatic anti-static epoxy paint
  2. Power Module Heat Sink: Extruded high-purity aluminum alloy finned radiator bonded to IGBT power bridge modules
  3. Main Control PCB: Double-layer high-temperature FR4 flame-retardant circuit board with gold-plated signal contact pins
  4. Power Semiconductor Assembly: Three-phase encapsulated IGBT power module filled with thermal conductive silicone gel
  5. Terminal Blocks: Nickel-plated copper screw terminal connectors with PA66 flame retardant insulation housing
  6. Cooling Fan Unit: Brushless DC centrifugal fan with stainless steel corrosion-resistant impeller
  7. PROFIBUS-DP Expansion Daughter Board: Miniature FR4 PCB with industrial bus signal isolation transformers

Structural Features

  1. Vertical modular stack layout with metal shielding partition physically separating high-voltage power circuit zone and low-signal control/communication zone to suppress industrial EMI interference
  2. Front panel equipped with three-digit LED fault status display and dedicated independent indicator lamps for overvoltage, overcurrent, overtemperature and feedback loss faults
  3. Tiered terminal layout: Top section for three-phase mains power terminals, middle section for motor power output terminals, bottom section for analog/digital I/O and PROFIBUS-DP bus wiring terminals
  4. Dedicated rear-side plug-in expansion slot pre-loaded with factory PROFIBUS-DP communication card, supporting hot-swap fieldbus hardware replacement
  5. Integrated encoder signal emulation output channel eliminates requirement for external position repeater hardware for secondary monitoring equipment
  6. RS232 multi-drop diagnostic port allows single PC connection to synchronously configure multiple cascaded S600 series drive units
  7. Removable fan intake filter screen for regular dust cleaning without drive disassembly

Working Principle

Three-phase industrial mains AC input passes integrated EMC filter to suppress grid conducted electromagnetic interference, then full-wave diode rectifier converts AC to stable DC bus voltage supplying three-phase IGBT power inverter stage. Main DSP controller executes space vector modulation (SVM) algorithm to generate high-frequency PWM gate drive signals, converting fixed DC bus voltage to variable frequency three-phase sinusoidal AC excitation current for connected servo motor stator windings. Real-time sine/cosine encoder feedback signals are sampled at 16kHz current loop cycle to close torque, velocity and position triple control loops; PDFF control algorithms dynamically adjust output current magnitude and phase angle to eliminate motor position tracking deviation. PROFIBUS-DP bus receives synchronized multi-axis motion commands from host PLC master controller, executing pre-stored electronic gearing, electronic cam and segmented motion trajectory tasks saved in on-board flash memory. Built-in axial fan continuously exhausts heat generated by power semiconductor switching loss through aluminum fin heat sink; internal fault monitoring circuit continuously samples all critical electrical and thermal operating parameters, triggering hardware interlock power stage shutdown upon threshold violation to prevent permanent hardware damage.

Function Features

  1. Automatic full-spectrum motor identification tuning wizard eliminating manual PID gain adjustment during equipment commissioning
  2. Onboard storage capacity for 300 editable independent motion trajectory tasks supporting complex segmented automation cycles
  3. Universal multi-feedback signal compatibility matching all Kollmorgen rotary, cartridge DDR and DDL linear servo motor feedback hardware
  4. Encoder signal emulation output channel providing secondary position signal for external secondary monitoring and auxiliary control axes
  5. PROFIBUS-DP industrial bus compatibility enables seamless integration with Siemens, Rockwell and all standard PROFIBUS master PLC systems
  6. Configurable restart lock safety (-AS) interlock function complying with EN 954-1 machinery safety standards for personnel hazard prevention
  7. DQ vector current control algorithm suppresses low-speed motor torque ripple below 0.5% of rated continuous torque
  8. Non-volatile fault data logging storage retaining 50 complete historical fault records with precise timestamp marking for failure diagnosis

Advantage Highlights

  1. Single integrated unit design with pre-installed EMC mains filter eliminates requirement for external filter accessory installation
  2. Maximum 400Hz velocity loop bandwidth delivers ultra-fast dynamic acceleration/deceleration response for high-speed packaging, printing and machine tool axes
  3. Modular fieldbus expansion architecture enables future system communication protocol upgrade without complete drive hardware replacement
  4. Full universal motor compatibility supporting all Kollmorgen AKM, Goldline, DDR, DDL series rotary and linear servo motor platforms
  5. UL, cUL, CE, RoHS, REACH global safety compliance certification for worldwide industrial OEM equipment deployment
  6. Complete galvanic isolation between high-voltage power circuits and low-voltage signal/communication circuits minimizing industrial site electromagnetic noise interference

Applicable Industries

Multi-axis CNC machine tools, automated robotic welding workcells, high-speed packaging conversion lines, laser cutting and ablation equipment, web-fed printing machinery, semiconductor backend packaging automation, aerospace precision test rigs, heavy-duty textile high-speed weaving equipment

Installation Requirements

  1. Mandatory vertical cabinet mounting orientation only; horizontal installation blocks fan forced airflow path and causes irreversible thermal damage to power modules
  2. Vertical stacking installation minimum clearance: 100 mm unobstructed vertical space above drive top surface, 50 mm clearance below drive bottom edge for fan exhaust airflow
  3. Cabinet ambient operating temperature limited to 0°C ~ +45°C; ambient temperature range 45°C ~ 55°C requires linear 20% continuous output current derate per 10°C temperature rise
  4. Mains three-phase power wiring specification: ≥2.5 mm² fully shielded copper cable with braided shielding layer
  5. Motor power wiring specification: For cable length ≤25 m, use 2.5 mm² four-core shielded motor cable; cable length exceeding 25 m requires matching external output choke accessory
  6. PROFIBUS-DP communication wiring: Standard twisted-pair shielded PROFIBUS bus cable, install 120Ω terminating resistor at both physical endpoints of the bus network
  7. Grounding rule: Cabinet mounting metal plate must connect to factory star earth grid via minimum 10 mm² solid copper protective earth conductor
  8. Cable separation regulation: High-voltage power cables and low-level signal/communication cables must route in physically independent cable ducts; unavoidable cross routing must adopt strict 90-degree perpendicular crossing only

Operation & Maintenance Precautions

  1. Control cabinet must maintain minimum IP54 protection rating to prevent conductive dust and metal particle ingress onto drive internal PCB circuits
  2. Strictly prohibit drive operation with damaged or removed cooling fan unit; fan failure leads to permanent power module thermal burnout within 15 continuous operating minutes
  3. Disconnect all three-phase mains AC supply and wait minimum 10 minutes for DC bus capacitor full discharge before disassembling any terminal wiring connectors
  4. Monthly maintenance task: Remove fan intake filter screen and fully clean accumulated dust with compressed dry air to maintain unobstructed cooling airflow
  5. All encoder and PROFIBUS communication cable shielding layers must implement double-end grounding to eliminate signal noise distortion and position jitter
  6. Regular firmware upgrade and parameter backup operations must exclusively execute via official Kollmorgen WorkBench configuration software; unapproved third-party firmware voids all factory warranty coverage
  7. Prohibit deployment of this drive inside control enclosures containing heavy oil mist, conductive carbon dust or acidic/alkaline corrosive vapor atmospheres
