Length: 12.0 Meters

Conductor Configuration: 3 Power Conductors (U/V/W) + PE + Feedback Conductors (Encoder/Resolver)

Shielding: Double Shield — Foil + Tinned Copper Braid (> 85% Coverage)

Outer Jacket Material: PUR (Polyurethane) — Oil, Abrasion, and UV Resistant

Rated Voltage: 300 V (Power) / 50 V (Signal)

Rated Current (Power): 46 A (Typical for this Gauge)

Operating Temperature: -20°C to +80°C (Continuous), -40°C to +105°C (Short Term)

Connector End A: Drive-Side M40 or M23 (Per Configuration)

Connector End B: Motor-Side M40 or M23 (Per Configuration)

Bend Radius (Min.): 5× Cable Diameter (Static), 10× Cable Diameter (Dynamic)

Cable Diameter (Approx.): 18 mm to 22 mm (Depending on Conductor Count)

Key Features:

• Kollmorgen Proprietary Cable Design for Optimal Motor Performance
• Low-Inductance Power Conductors for Fast Torque Response
• EMI-Optimized Shielding for Encoder Signal Integrity
• Millions of Flex Cycles Rated
• Pre-Tested for Kollmorgen Drive/Motor Pairing

Applicable Industries: Universal — All Kollmorgen AKD/AKD-T to AKM/DBL/WKS Motor Installations

Installation Requirements: Route in Dedicated Cable Carrier, Maintain 100 mm Separation from High-Voltage Cables, Ground Shield at Drive End Only (Per Kollmorgen Guidelines for Resolver Cables), Secure with Clamps Every 500 mm on Moving Axes
